Instruction Manual CyberComm 6000
11
1.5 Getting Familiar with CyberComm
1.5.1 Overview
The user interface of CyberComm 6000 has the following main sections.
ƒ Menu bar
ƒ Control tabs
ƒ Workspace
Figure 12 : Menu bar, Control tabs & Workspace
1.5.2 Menu bar
Menu bar has menus and sub-menus to perform common tasks
1.5.3 Control tabs
Control tabs consist of three tabs:
Project: Project related activities are carried out in this tab. Read more about
projects (page 19)
Measure: Meter related activities are carried out in this tab. You can select
multiple channels and measuring parameters form the left-pane. The right-
pane (workspace) displays 6 tabs (Measure, Standardization, Setup, Display
Menu bar
Control tabs
Workspace
