Instruction Manual CyberComm 6000
6
1.3 Connecting to CyberScan 6000 Series Meter
The Cybercomm 6000 Data Acquisition software is able to communicate with any
CyberScan 6000 series meter (PH6000 / PC6000 / PH6500 / CON6000 / DO6000 /
PC6500 / PCD6500) via RS232 serial port connection.
1.3.1 RS232 Serial Port Connection
1. Connect RS232 serial communication cable to RS232 port of the back panel of
CyberScan 6000 series meter.
2. Connect the other end of the cable to serial communication (COM) port of your
PC. If you use a serial communication port other than COM1, you need to specify
it in CyberComm configuration settings. Refer ‘COM Port Configuration’ in page
16.
1.3.2 Prepare the Meter for Communication
1. Make sure the required pH, DO, Conductivity probes are connected to the back
panel of the CyberScan 6000 series meter. (Refer the instruction manual of the
meter for more details)
2. Power on the meter. The CyberScan application starts automatically.
3. Tap Logoff button to exit form CyberScan application.
4. Start ADCServer. Double-tap on ‘ADCServer’ icon available in the
Desktop of the meter. The ADC Server application window appears.
(Figure 7)
Note: The meter cannot be connected to the CyberComm software when
the CyberScan application is running. You need to exit the CyberScan
application before you can start communicating with CyberComm.
