7
2.3.2 Indication of low battery voltage
If the remaining battery decreases below the specified amount, the battery voltage is lowered
and the number display is changed to indicate the current setting value and "LLLLLL" alternately.
Emission can be performed even when the battery voltage is low.
If the remaining battery decreases further, the number display indicates only "LLLLLL", which
provides the emission stop status. Press the power switch, and shut off the power immediately.
In either case, charge the unit according to the procedure in "2.3.1 Charging method" .
•Indication of low battery voltage
INT EXT
FPM
DUR
PHA
Indicates alternately
INT EXT
FPM
DUR
PHA
•Indication of emission stop
INT EXT
FPM
DUR
PHA
2.3.3 Battery replacement
CAUTION
When replacing the battery, be sure to turn off the stroboscope main unit.
Do not touch the metal part of the connecter.
If the battery-life duration becomes short, replace the battery with one that is specified.
For a new battery, contact our dealer where you purchased this unit.
(1) Remove the four screws on both ends of the bottom of the DT-365E main unit, and take out the
built-in battery.
(2) Remove the connector and battery fixing screws, and replace with a new battery.
(3) Secure the new battery using fixing screws and connect the connector to it.
(4) Mount the built-in battery in the main unit.
Connector
Built-in battery
Place the hole toward
the front of the unit and secure.
Secure the battery so that
the harness faces the front side.
