24

5 Specifications

Model

DT-365E

Application

Charging battery built-in model

Internal

oscillation

emission

Emission count

60 to 120,000 fpm

Setting accuracy

±0.02%

Measurement range setting

Available to set to the range between 60 fpm and 120,000 fpm, or 60 fpm

and 12,000 fpm

(Set in function mode 1)

Setting

display

resolution

(Internal

oscillation)

Measurement

range:

60 to 12,000 fpm

60.0 to 3,000.0

: 0.1fpm

3,000.2 to 6,000.0 : 0.2fpm

6,000.5 to 12,000.0 : 0.5fpm

Measurement

range:

60 to 120,000 fpm

60 to 30,000

: 1fpm

30,00.2 to 60,000 : 2fpm

60,00.5 to 100,000 : 5fpm

100,010 to 120,000 : 10fpm

Function to change the emission

frequency setting

Available to change the emission frequency to an optional value

Available to change the emission frequency to double or half of the

current value

(Each press of the key changes the value to double, quadruple..., or half,

one-quarter, ...)

Phase change function

When the angle is set based on the current emission phase: within the

range between 0 and 359º, available to set by 1º

External

synchronous

emission

External trigger pulse input interface

NPN open collector input (input impedance: 4.7 kΩ)

Delay caused by the internal calculation process (pulse input to

emission): 20 μs

External trigger pulse output

interface

NPN open collector output pulse width: approx. 150 μs

Delay caused by the internal calculation process (emission to pulse

output): 10 μs

Synchronous edge switch

Available to select either the rising edge or falling edge

(Set in function mode 2)

Frequency measurement range

40 to 35,000fpm

Available delay emission range

60 to 10,000fpm

Available phase setting range

Delay angle: by 1º within the range between 0º and 359º

Emission

duration

Angle

Available to set by 0.1º within the range between 0.1º and 3.6º (/360º)

Display

6-digit red LED

Setting devices

Multi-turn encoder, tact switch

Emission source

Ultra luminosity LED 6 lights

Signal I/O

Phone jack (φ3.5mm, 2 poles)
