6
2.2 Peeling off the protection sheet
Peel off the protection sheet on the operation section.
Operation section
Peel off the (transparent) protection sheet
2.3 Charging
Be sure to charge the battery before initial use. Before charging, be sure to check that the power is
turned OFF.
2.3.1 Charging method
Turn the power OFF, and connect the supplied AC adapter's connector to the main unit. Next
insert the AC adapter's AC plug into an outlet. The battery lamp lights up, and charging starts.
Charging is complete in approximately 2.5 hours, and then the charging lamp goes off.
Connect the supplied AC adapter
Note 1) Since the battery current is automatically shut off when charging is complete, there is no need
to worry about overcharging.
Note 2) When the power is turned ON during charging, charging is canceled and emission starts. When
the unit uses the AC adapter as its power source, it is not charged. (Note that emission and
charging cannot be performed simultaneously.)
Note 3) Though the unit can be charged while battery power still remains, charging will still end when
fully charged. It is recommended, however, that the unit be charged when the battery has run
out ("LLLLLL" is indicated on the number display) to avoid reducing the battery life itself.
Note 4) If the unit is charged immediately after a long emission time at a high ambient temperature,
the temperature rise protection circuit will turn on, and the charging lamp may not light up. In
that case, disconnect the AC adapter, and let the unit cool. When the product temperature is
decreased, connect the AC adapter again, and start charging.
Note 5) Never charge the unit under the following conditions.
Adapter of
another device
・ Charging near flammable materials ・ Using another AC adapter than supplied
Oil
