Martel Electronics BetaGauge 3II User Manual

Page 4

3- Basic Operations ......................................... 3-1

Overview................................................................ 3-1
Selecting a Channel for Specific Functions ........... 3-2

Procedure ........................................................... 3-2

Selecting Pre-Programmed Display Units.............. 3-3

BetaPort–DC Module ........................................ 3-3
BetaPort–P Pressure Module ............................. 3-4

Selecting a Water Column Measurement ....... 3-5

Procedure ................................................... 3-6

Zeroing Modules.................................................... 3-6

Zeroing Pressure Modules ................................. 3-7

Zeroing a Gauge Zero Reference Module...... 3-7
Zeroing an Absolute Zero Reference Module 3-8

Zeroing DC Modules .......................................3 -10

Zeroing the Volts Input ................................3 -10
Zeroing the Milliamp Input ..........................3 -11

Setting the Damping Factor for Ch1/Ch2 ............3 -12

Reset Damping Guidelines............................... 3 -13
Procedure ......................................................... 3 -13

Viewing Module Information ..............................3 -14

Procedure ......................................................... 3 -14

Programming Trip Detection ............................... 3 -15

Wet Contacts....................................................3 -15
Dry Contacts ....................................................3 -16
Hints for Accurate Trip Measurements............3 -16

Field Instrument Selection ........................... 3 -16
Pressure Source Adjustment ........................3 -17
Pressure Signal Ramping ............................. 3 -17

Preliminary Setup ............................................3 -18
Procedure ......................................................... 3 -19

4- User Preferences ......................................... 4-1

Overview................................................................ 4-1
Programming and Viewing Calibrator Information 4-2

Entering Owner Identification ........................... 4-2
Viewing Calibrator Information......................... 4-3

Turning the Keypad Beep On/Off.......................... 4-3

Procedure ........................................................... 4-3
