4
OPERATION
48
OPTIFLEX 2200 C
www.krohne.com 09/2013 - 4002573201 - AD FF OPTIFLEX 2200 R01 en
TEMPERATURE_OUT_OF_ TEMPERATURE_OUT_OF_ TEMPERATURE_OUT_OF_ TEMPERATURE_OUT_OF_
RANGE RANGE RANGE RANGE
Temperature Out of Range Temperature Out of Range Temperature Out of Range Temperature Out of Range
RW Temperature Out of Range Alarm
Setting:
Warning / Error
TRACING_VELOCITY TRACING_VELOCITY TRACING_VELOCITY TRACING_VELOCITY
Tracing velocity Tracing velocity Tracing velocity Tracing velocity
RW This function sets the maximum rate of change of level. The
measured value cannot change faster than the tracing
velocity.
TIME_CONST TIME_CONST TIME_CONST TIME_CONST
Time constant Time constant Time constant Time constant
RW Using this function, the device processes several
measurement readings to filter out disturbances. Increasing
the time constant will smoothen the integrated readings,
decreasing will roughen the readings.
TRANSDUCER_DIRECTORY TRANSDUCER_DIRECTORY TRANSDUCER_DIRECTORY TRANSDUCER_DIRECTORY
Transducer Directory Entry Transducer Directory Entry Transducer Directory Entry Transducer Directory Entry
A directory that specifies the number and starting indices of
the data collections in the Transducer Block.
TRANSDUCER_TYPE TRANSDUCER_TYPE TRANSDUCER_TYPE TRANSDUCER_TYPE
Transducer Type Transducer Type Transducer Type Transducer Type
R Identifes the transducer that follows. Other
UNIT_CONVERSION UNIT_CONVERSION UNIT_CONVERSION UNIT_CONVERSION
unit conversion unit conversion unit conversion unit conversion
RW Unit used for entries in conversion table
Setting:
gal; L; ImpGal; m³; bbl; ft³; m; cm; mm; in; ft; kg; t; STon; LTon
UNIT_LENGTH UNIT_LENGTH UNIT_LENGTH UNIT_LENGTH
unit length unit length unit length unit length
RW Unit used for length parameter
Setting:
m; cm; mm; in; ft
VOLUME_OF_POINT_1_15 VOLUME_OF_POINT_1_15 VOLUME_OF_POINT_1_15 VOLUME_OF_POINT_1_15
Mass/volume conversion Mass/volume conversion Mass/volume conversion Mass/volume conversion
table table table table
RW Mass/volume values 1-15 corresponding to the entries in the
level table.
VOLUME_OF_POINT_6_30 VOLUME_OF_POINT_6_30 VOLUME_OF_POINT_6_30 VOLUME_OF_POINT_6_30
Mass/volume conversion Mass/volume conversion Mass/volume conversion Mass/volume conversion
table table table table
RW Mass/volume values 16-30 corresponding to the entries in the
level table.v
XD_ERROR XD_ERROR XD_ERROR XD_ERROR
Transducer Error Transducer Error Transducer Error Transducer Error
R One of the transducer error codes defined in section 4.7
"Block Alarm Subcodes" of the FF Transducer Specifications.
Uninitialized
Setting:
Unspecified error / General error / Calibration error /
Configuration error / Electronics Failure / Mechanical
Failure / I/O Failure / Data Integrity Error / Software Error /
Algorithm Error
Parameter Parameter Parameter Parameter
DD name Access Description and settings Initial Value
