OPERATION
4
45
OPTIFLEX 2200 C
www.krohne.com 09/2013 - 4002573201 - AD FF OPTIFLEX 2200 R01 en
PRIMARY_VALUE_1 PRIMARY_VALUE_1 PRIMARY_VALUE_1 PRIMARY_VALUE_1
Level Level Level Level
The measured level value and status of available to the
Function Block.
-
STATUS
Status
R Digital transducers, unlike their analog versions, can detect
faults that make the measurement bad or prevent the
actuator from responding. This additional, valuable
information will be passed along with each transmission of a
data value in the form of a status attribute.
-
VALUE
Value
R A numerical quantity entered by a user or calculated by the
algorithm.
-
PRIMARY_VALUE_ PRIMARY_VALUE_ PRIMARY_VALUE_ PRIMARY_VALUE_
RANGE_1 RANGE_1 RANGE_1 RANGE_1
Primary Value Primary Value Primary Value Primary Value
Range - Sensor 1 Range - Sensor 1 Range - Sensor 1 Range - Sensor 1
The High and Low range limit values, the engineering units
code and the number of digits to the right of the decimal point
to be used to display the Primary Value.
-
EU_100
max value
R The engineering unit value which represents the upper end of
range of the associated block parameter.
100
EU_0
min value
R The engineering unit value which represents the lower end of
range of the associated block parameter.
0.0
UNITS_INDEX
Units Index
RW Device Description units code index for the engineering unit
descriptor for the associated block value.
m
Settings:
m; cm; mm; in; ft
DECIMAL
Decimal
R The number of digits to the right of the decimal point which
should be used by an interface device in displaying the
specified parameter.
0
PRIMARY_VALUE_TYPE2 PRIMARY_VALUE_TYPE2 PRIMARY_VALUE_TYPE2 PRIMARY_VALUE_TYPE2
Primary Value Type Primary Value Type Primary Value Type Primary Value Type
R The type of measurement represented by the primary value.
For Example: Mass Flow, Absolute Pressure, Differential
Temperature.
distance
PRIMARY_VALUE_2 PRIMARY_VALUE_2 PRIMARY_VALUE_2 PRIMARY_VALUE_2
Distance Distance Distance Distance
The measured distance value and status of available to the
Function Block.
-
STATUS
Status
R Digital transducers, unlike their analog versions, can detect
faults that make the measurement bad or prevent the
actuator from responding. This additional, valuable
information will be passed along with each transmission of a
data value in the form of a status attribute.
-
VALUE
Value
R A numerical quantity entered by a user or calculated by the
algorithm.
-
PRIMARY_VALUE_ PRIMARY_VALUE_ PRIMARY_VALUE_ PRIMARY_VALUE_
RANGE_2 RANGE_2 RANGE_2 RANGE_2
Primary Value Primary Value Primary Value Primary Value
Range - Sensor 2 Range - Sensor 2 Range - Sensor 2 Range - Sensor 2
The High and Low range limit values, the engineering units
code and the number of digits to the right of the decimal point
to be used to display the Primary Value.
EU_100
max value
R The engineering unit value which represents the upper end of
range of the associated block parameter.
100
EU_0
min value
R The engineering unit value which represents the lower end of
range of the associated block parameter.
0.0
UNITS_INDEX
Units Index
RW Device Description units code index for the engineering unit
descriptor for the associated block value.
m
Settings:
m; cm; mm; in; ft
DECIMAL
Decimal
R The number of digits to the right of the decimal point which
should be used by an interface device in displaying the
specified parameter.
0
PRIMARY_VALUE_TYPE_3 PRIMARY_VALUE_TYPE_3 PRIMARY_VALUE_TYPE_3 PRIMARY_VALUE_TYPE_3
Primary Value Type Primary Value Type Primary Value Type Primary Value Type
R The type of measurement represented by the primary value.
For Example: Mass Flow, Absolute Pressure, Differential
Temperature.
conversion
PRIMARY_VALUE_3 PRIMARY_VALUE_3 PRIMARY_VALUE_3 PRIMARY_VALUE_3
Conversion Conversion Conversion Conversion
The measured conversion value and status of available to the
Function Block.
Parameter Parameter Parameter Parameter
DD name Access Description and settings Initial Value
