OPERATION
4
43
OPTIFLEX 2200 C
www.krohne.com 09/2013 - 4002573201 - AD FF OPTIFLEX 2200 R01 en
UNACKNOWLEDGED
Unacknowledged
R/W A discrete enumeration which is set to "Unacknowledged"
when an alarm occurs, and set to "Acknowledged" by a write
from a human interface device or other entity which can
acknowledge that the alarm/event has been noticed.
Uninitialized
Setting:
Uninitialized / Acknowledged / Unacknowledged
UPDATE_STATE
Update State
R A discrete enumeration which gives an indication of whether
the alert has been reported.
Uninitialized
Setting:
Uninitialized / Update reported / Update not reported
TIME_STAMP
Time Stamp
R The time when evaluation of the block was started and a
change in alarm/event state was detected that is unreported.
The time stamp value will be maintained constant until alert
confirmation has been received - even if another change of
state occurs.
Uninitialized
Setting:
MM / DD / YY (Month / Day / Year)
HH:MM:SS (Hour:Minute:Second)
STATIC_REVISION
Static Revision
R The static revision of the block whose static parameter was
changed and is being reported. It is possible for the present
value of static revision to be greater than this because static
can be changed at any time.
0
Setting:
0…65535
RELATIVE_INDEX
Relative Index
R The OD index of the static parameter whose change caused
this alert, minus the FB starting index. If the update event was
caused by a write to multiple parameters at the same time,
then this attribute will be zero.
0
Setting:
0…65535
AUTO_EPSILON_R AUTO_EPSILON_R AUTO_EPSILON_R AUTO_EPSILON_R
Automatic calculation of Automatic calculation of Automatic calculation of Automatic calculation of
dielectric constant dielectric constant dielectric constant dielectric constant
RW Enables/disables automatic calculation of the dielectric
constant of the filling medium.
Setting:
No / Yes
BLOCKING_DISTANCE BLOCKING_DISTANCE BLOCKING_DISTANCE BLOCKING_DISTANCE
Blocking Distance Blocking Distance Blocking Distance Blocking Distance
RW The non-measuring range at the top of the probe. It depends
on the probe type and the installation.
Setting:
0...PROBE_LENGTH
CAL_MIN_SPAN CAL_MIN_SPAN CAL_MIN_SPAN CAL_MIN_SPAN
Calibration Minimum Span Calibration Minimum Span Calibration Minimum Span Calibration Minimum Span
R The minimum calibration span allowed. Ensures that the two
calibrated points (high and low) are not too close together.
CAL_POINT_HI CAL_POINT_HI CAL_POINT_HI CAL_POINT_HI
Calibration Highest Point Calibration Highest Point Calibration Highest Point Calibration Highest Point
R The highest calibrated value.
CAL_POINT_LO CAL_POINT_LO CAL_POINT_LO CAL_POINT_LO
Calibration Lowest Point Calibration Lowest Point Calibration Lowest Point Calibration Lowest Point
R The lowest calibrated value.
CAL_UNIT CAL_UNIT CAL_UNIT CAL_UNIT
Calibration Units Calibration Units Calibration Units Calibration Units
R The Device description engineering units code index for the
calibration values.
CALSPEED_ELECTRONIC CALSPEED_ELECTRONIC CALSPEED_ELECTRONIC CALSPEED_ELECTRONIC
Electronics Calspeed Electronics Calspeed Electronics Calspeed Electronics Calspeed
RW Electronics Calspeed
CALSPEED_MECHANIC CALSPEED_MECHANIC CALSPEED_MECHANIC CALSPEED_MECHANIC
Mechanical Calspeed Mechanical Calspeed Mechanical Calspeed Mechanical Calspeed
RW Mechanical Calspeed
COLLECTION_DIRECTORY COLLECTION_DIRECTORY COLLECTION_DIRECTORY COLLECTION_DIRECTORY
Collection Directory Collection Directory Collection Directory Collection Directory
A directory that specifies the number, starting indices and DD
Item IDs of the data collections in each transducer within a
Transducer Block.
-
Parameter Parameter Parameter Parameter
DD name Access Description and settings Initial Value
