Page 75
User's Guide
Control Panel 4-13
Figure 4-4. Setup Menu
PARAMETER
DEFAULT
OTHER
SETTING
SETTINGS
OPERATIONS
1) RSTOR:
None
Usr 1 Usr 2 Usr 3 Usr 4 Usr 5 Fctry
2) SAVE:
None
Usr 1 Usr 2 Usr 3 Usr 4 Usr 5
3) DFALT:
Fctry
Usr 1 Usr 2 Usr 3 Usr 4 Usr 5
4) TEST:
None
Memory Sensor Ribbon Align Pcalib Random Gap
PRINTER SETUP
5) EMUL:
AMT
Diab630 EpsonJX EpsonLQ IBMXL24 Barcode HexMode
6) QUIET:
Off
On
7) LANG:
USA
French German UK Dansh1 Swedsh Italn Spnsh1
Jpnese Norwgn Dansh2 Spnsh2 Portgs
8) SETS:
IBM1
IBM2 Ital1 Ital2 None
9) AUTO CR:
Off
On
10) AUTO LF:
Off
On
11) ERRBEL:
Once
Dcay Cont
TEXT APPEARANCE
12) QUAL:
Letter
Memo Draft
13) FONT:
Courier
Gothic TmsRomn Elite
14) PITCH:
10
12 13.3 15 17.1 20 PS
15) CELL:
10
12 13.3 15 17.1 20 PS
16) LPI:
6
2 3 4 5 8 9 10 12
17) COLOR:
Black
Cyan Mgnta Yellw Violt Green Orang
18) ITALICS:
Off
On
19) HIGH:
Off
On
20) WIDE:
Off
On
21) SCRIPT:
Off
Sub Supr
22) UNDLINE:
Off
On
23) BLD/SHA:
Off
Bld Sha
24) SLASH-0:
Off
On
25) BI-DIR:
Text
Graf Full Off
PAGE SETUP
26) LENG:
66/6"
0/6" to 182/6"
27) WIDTH:
8.5"
8" 11" (settings for narrow-carriage printers)
13.6"
8" 16" (settings for wide-carriage printers)
2 8 ) TOP MAR:
0
0 to 363
2 9 ) BOT MAR:
6 6
1 to 364
3 0 ) LFT MAR:
0
0 to 169
3 1 ) RGT MAR:
8 5
1 to 170
3 2 ) AUTO FF:
O f f
O n
PAPER HANDLING
3 3 ) P A T H :
T o p
Rear TopTrac Bottom
3 4 ) L F S L E W :
6 i p s
1ips to 10ips
3 5 ) D E M A N D :
O f f
On Beep Tear Auto
3 6 ) PPR JAM:
O n
O f f
3 7 ) PGE END:
O f f
On Roll
3 8 ) P O P U P :
O f f
O n
3 9 ) A U T O B A I L :
O f f
O n
4 0 ) PH GAP:
A u t o
10 to 45
4 1 ) P F O R C E :
A u t o
1 to 10
