User's Guide

3-4 Loading Paper

Loading Forms

Figure 3-2. Attaching the Support Extenders

You load forms from the top of the printer.
After loading a form, the printer automati-
cally positions it to the first printable line.
After printing, the printer ejects the form.
If the printer has more information to print,
the LOAD PAPER message appears on the
control panel display to notify you.

To load a form, use this procedure:

1. Move the tractor select lever to activate

the top path ( ).

2. Raise the paper support. If necessary for

long forms, attach the paper support
extenders, as shown in figure 3-2.

3. Squeeze the rear clip on the left paper

edge guide and position the guide so that
it aligns with the "0" ( ) on the paper
scale.

4. Set a sheet into the left paper edge guide.

Then, squeeze the rear clip on the right
paper edge guide and position the guide
up against the right edge of the form, as
shown in figure 3-3.

5. Press the Form Feed button. The form

will advance into the printer.

) Note: Use of the right paper edge guide

is highly recommended for long, multi-
sheet forms printing.

Figure 3-3. Loading a Form

User's Guide

3-4 Loading Paper

Loading Forms

Figure 3-2. Attaching the Support Extenders

You load forms from the top of the printer.
After loading a form, the printer automati-
cally positions it to the first printable line.
After printing, the printer ejects the form.
If the printer has more information to print,
the LOAD PAPER message appears on the
control panel display to notify you.

To load a form, use this procedure:

1. Move the tractor select lever to activate

the top path ( ).

2. Raise the paper support. If necessary for

long forms, attach the paper support
extenders, as shown in figure 3-2.

3. Squeeze the rear clip on the left paper

edge guide and position the guide so that
it aligns with the "0" ( ) on the paper
scale.

4. Set a sheet into the left paper edge guide.

Then, squeeze the rear clip on the right
paper edge guide and position the guide
up against the right edge of the form, as
shown in figure 3-3.

5. Press the Form Feed button. The form

will advance into the printer.

) Note: Use of the right paper edge guide

is highly recommended for long, multi-
sheet forms printing.

Figure 3-3. Loading a Form
