User's Guide

D-14 Code Sets

Table D-3. AMT and Diablo 630 Escape Sequences––continued

Function

ASCII

Hexadecimal

Decimal

Description

Text Functions––continued

Download font coding ........

ESC @ D

1B 40 44

27 64 68

This sequence downloads a font to the printer. Variable a1

a1 a2 n1 n2

a1 a2 n1 n2

a1 a2 n1 n2

is the number assigned to the font. The Set Font escape

coding

coding

coding

sequence uses this number to identify and select the font.
Normally, the first font downloaded is assigned 255 (FF
hex), the second font downloaded is assigned 254 (FE hex),
and so on. Variable a2 must always be 00 hex. Variable
n2 and n1 are a 16-bit number that specifies the number of
bytes in the font coding. Variable n2 is the high-order byte;
n1 is the low-order byte. The font coding must conform to
a prescribed binary coding format.

Note: For more detailed information on this escape se-
quence, refer to AMT Technical Notes––Downloading
Fonts,
available separately from AMT.

Print character assigned ...

ESC Y

1B 59

27 89

This sequence prints the character assigned to code 20 hex,

to code 20 hex

which the printer normally interprets as a space.

Print character assigned ...

ESC Z

1B 5A

27 90

This sequence prints the character assigned to code 7F hex,

to code 7F hex

which the printer normally ignores.

Start print suppression .....

ESC 7

1B 37

27 55

This sequence starts the print supression mode, wherein the
printer replaces all printable characters with spaces. A
carriage return ends the print suppression mode.

Set language .......................

ESC @ G n

1B 40 47 n

27 64 71 n

This sequence selects a language for the printer to use

English (US) ...................

ESC @ G NUL

1B 40 47 00

27 64 71 0

while printing text. The language settings causes the

French ............................

ESC @ G SOH

1B 40 47 01

27 64 71 1

printer to replace some of the standard characters with

German ...........................

ESC @ G STX

1B 40 47 02

27 64 71 2

alternate characters that are used in a specific language.

English (UK) ..................

ESC @ G ETX

1B 40 47 03

27 64 71 3

The character replacements are shown in the Control

Danish I ..........................

ESC @ G EOT

1B 40 47 04

27 64 71 4

Panel section of this guide, under the Set Language

Swedish ..........................

ESC @ G ENQ

1B 40 47 05

27 64 71 5

heading.

Italian .............................

ESC @ G ACK

1B 40 47 06

27 64 71 6

Spanish I ........................

ESC @ G BEL

1B 40 47 07

27 64 71 7

Note: This sequence applies only to fonts with inter-

Japanese .........................

ESC @ G BS

1B 40 47 08

27 64 71 8

national characters.

Norwegian ......................

ESC @ G HT

1B 40 47 09

27 64 71 9

Danish II ........................

ESC @ G LF

1B 40 47 0A

27 64 71 10

Spanish II .......................

ESC @ G VT

1B 40 47 0B

27 64 71 11

Portuguese ......................

ESC @ G FF

1B 40 47 0C

27 64 71 12

Backward printing

These sequences control backward printing, wherein the

Start ................................

ESC 6

1B 36

27 54

printer reverses the direction of normal spacing, back-

End .................................

ESC 5

1B 35

27 53

spacing, and character escapement. A space moves the
current print position one space to the left, a backspace
moves the current print position to the right, and character
escapement is to the left. Backward printing does not affect
horizontal tabbing or absolute moves, carriage returns, or
paper movement functions. A carriage return or End
Backward Printing
sequence ends backward printing.

User's Guide

D-14 Code Sets

Table D-3. AMT and Diablo 630 Escape Sequences––continued

Function

ASCII

Hexadecimal

Decimal

Description

Text Functions––continued

Download font coding ........

ESC @ D

1B 40 44

27 64 68

This sequence downloads a font to the printer. Variable a1

a1 a2 n1 n2

a1 a2 n1 n2

a1 a2 n1 n2

is the number assigned to the font. The Set Font escape

coding

coding

coding

sequence uses this number to identify and select the font.
Normally, the first font downloaded is assigned 255 (FF
hex), the second font downloaded is assigned 254 (FE hex),
and so on. Variable a2 must always be 00 hex. Variable
n2 and n1 are a 16-bit number that specifies the number of
bytes in the font coding. Variable n2 is the high-order byte;
n1 is the low-order byte. The font coding must conform to
a prescribed binary coding format.

Note: For more detailed information on this escape se-
quence, refer to AMT Technical Notes––Downloading
Fonts,
available separately from AMT.

Print character assigned ...

ESC Y

1B 59

27 89

This sequence prints the character assigned to code 20 hex,

to code 20 hex

which the printer normally interprets as a space.

Print character assigned ...

ESC Z

1B 5A

27 90

This sequence prints the character assigned to code 7F hex,

to code 7F hex

which the printer normally ignores.

Start print suppression .....

ESC 7

1B 37

27 55

This sequence starts the print supression mode, wherein the
printer replaces all printable characters with spaces. A
carriage return ends the print suppression mode.

Set language .......................

ESC @ G n

1B 40 47 n

27 64 71 n

This sequence selects a language for the printer to use

English (US) ...................

ESC @ G NUL

1B 40 47 00

27 64 71 0

while printing text. The language settings causes the

French ............................

ESC @ G SOH

1B 40 47 01

27 64 71 1

printer to replace some of the standard characters with

German ...........................

ESC @ G STX

1B 40 47 02

27 64 71 2

alternate characters that are used in a specific language.

English (UK) ..................

ESC @ G ETX

1B 40 47 03

27 64 71 3

The character replacements are shown in the Control

Danish I ..........................

ESC @ G EOT

1B 40 47 04

27 64 71 4

Panel section of this guide, under the Set Language

Swedish ..........................

ESC @ G ENQ

1B 40 47 05

27 64 71 5

heading.

Italian .............................

ESC @ G ACK

1B 40 47 06

27 64 71 6

Spanish I ........................

ESC @ G BEL

1B 40 47 07

27 64 71 7

Note: This sequence applies only to fonts with inter-

Japanese .........................

ESC @ G BS

1B 40 47 08

27 64 71 8

national characters.

Norwegian ......................

ESC @ G HT

1B 40 47 09

27 64 71 9

Danish II ........................

ESC @ G LF

1B 40 47 0A

27 64 71 10

Spanish II .......................

ESC @ G VT

1B 40 47 0B

27 64 71 11

Portuguese ......................

ESC @ G FF

1B 40 47 0C

27 64 71 12

Backward printing

These sequences control backward printing, wherein the

Start ................................

ESC 6

1B 36

27 54

printer reverses the direction of normal spacing, back-

End .................................

ESC 5

1B 35

27 53

spacing, and character escapement. A space moves the
current print position one space to the left, a backspace
moves the current print position to the right, and character
escapement is to the left. Backward printing does not affect
horizontal tabbing or absolute moves, carriage returns, or
paper movement functions. A carriage return or End
Backward Printing
sequence ends backward printing.
