background image

User's Guide

Code Sets D-47

Table D-6. Epson and IBM Escape Sequences––continued

Function

ASCII

Hexadecimal

Decimal

Description

Graphic Functions––continued

Print single-density ............

ESC K n1 n2

1B 4B n1 n2

27 75 n1 n2

This sequence prints single-density graphics at 72V x 60H

graphics

list

list

list

dots per inch. Variables n1, n2 and list in the sequence
operate the same as in the Print Epson JX Graphics
sequence.

Print low-speed, double- ...

ESC L n1 n2

1B 4C n1 n2

27 76 n1 n2

This sequence prints low-speed, double-density graphics

density graphics

list

list

list

at 72V x 120H dots per inch. Variables n1, n2 and list in
the sequence operate the same as in the Print Epson JX
Graphics
sequence.

Print high-speed, double- ..

ESC Y n1 n2

1B 59 n1 n2

27 89 n1 n2

This sequence prints high-speed, double-density graphics

density graphics

list

list

list

at 72V x 120H dots per inch. Variables n1, n2 and list in
the sequence operate the same as in the Print Epson JX
Graphics
sequence. In this graphics mode, consecutive
horizontal dots are not permitted. If the sequence
specifies consecutive horizontal dots, the printer does not
print the second dot.

Print quadruple-density ....

ESC Z n1 n2

1B 5A n1 n2

27 90 n1 n2

This sequence prints quadruple-density graphics at

graphics

list

list

list

72V x 240H dots per inch. Variables n1, n2 and list in
the sequence operate the same as in the Print Epson JX
Graphics
sequence. In this graphics mode, consecutive
horizontal dots are not permitted. If the sequence
specifies consecutive horizontal dots, the printer does not
print the second dot.

Reassign alternate .............

ESC ? n1 n2

1B 3F n1 n2

27 63 n1 n2

This sequence reassigns the function of ESC K, ESC L,

graphics mode

ESC Y, or ESC Z, so that it performs any one of the other
six Epson graphics modes. Variable n1 defines which
sequence to reassign:

Sequence Variable n1
to Reassign ASCII Hex Dec

ESC K

K

4B

75

ESC L

L

4C

76

ESC Y

Y

59

89

ESC Z

Z

5A

90

Variable n2 defines which graphics mode to assign to the
selected sequence:

Variable n2

Mode Resolution ASCII Hex Dec

Single

72V x 60H dpi

NUL

00

0

Double

72V x 120H dpi SOH

01

1

HS double

72V x 120H dpi STX

02

2

Quadruple

72V x 240H dpi ETX

03

3

Epson QX-10 72V x 80H dpi

EOT

04

4

One-to-one

72V x 72H dpi

ENQ

05

5

Other CRTs 72V x 90H dpi

ACK

06

6

User's Guide

Code Sets D-47

Table D-6. Epson and IBM Escape Sequences––continued

Function

ASCII

Hexadecimal

Decimal

Description

Graphic Functions––continued

Print single-density ............

ESC K n1 n2

1B 4B n1 n2

27 75 n1 n2

This sequence prints single-density graphics at 72V x 60H

graphics

list

list

list

dots per inch. Variables n1, n2 and list in the sequence
operate the same as in the Print Epson JX Graphics
sequence.

Print low-speed, double- ...

ESC L n1 n2

1B 4C n1 n2

27 76 n1 n2

This sequence prints low-speed, double-density graphics

density graphics

list

list

list

at 72V x 120H dots per inch. Variables n1, n2 and list in
the sequence operate the same as in the Print Epson JX
Graphics
sequence.

Print high-speed, double- ..

ESC Y n1 n2

1B 59 n1 n2

27 89 n1 n2

This sequence prints high-speed, double-density graphics

density graphics

list

list

list

at 72V x 120H dots per inch. Variables n1, n2 and list in
the sequence operate the same as in the Print Epson JX
Graphics
sequence. In this graphics mode, consecutive
horizontal dots are not permitted. If the sequence
specifies consecutive horizontal dots, the printer does not
print the second dot.

Print quadruple-density ....

ESC Z n1 n2

1B 5A n1 n2

27 90 n1 n2

This sequence prints quadruple-density graphics at

graphics

list

list

list

72V x 240H dots per inch. Variables n1, n2 and list in
the sequence operate the same as in the Print Epson JX
Graphics
sequence. In this graphics mode, consecutive
horizontal dots are not permitted. If the sequence
specifies consecutive horizontal dots, the printer does not
print the second dot.

Reassign alternate .............

ESC ? n1 n2

1B 3F n1 n2

27 63 n1 n2

This sequence reassigns the function of ESC K, ESC L,

graphics mode

ESC Y, or ESC Z, so that it performs any one of the other
six Epson graphics modes. Variable n1 defines which
sequence to reassign:

Sequence Variable n1
to Reassign ASCII Hex Dec

ESC K

K

4B

75

ESC L

L

4C

76

ESC Y

Y

59

89

ESC Z

Z

5A

90

Variable n2 defines which graphics mode to assign to the
selected sequence:

Variable n2

Mode Resolution ASCII Hex Dec

Single

72V x 60H dpi

NUL

00

0

Double

72V x 120H dpi SOH

01

1

HS double

72V x 120H dpi STX

02

2

Quadruple

72V x 240H dpi ETX

03

3

Epson QX-10 72V x 80H dpi

EOT

04

4

One-to-one

72V x 72H dpi

ENQ

05

5

Other CRTs 72V x 90H dpi

ACK

06

6
