User's Guide

Code Sets D-13

Table D-3. AMT and Diablo 630 Escape Sequences––continued

Function

ASCII

Hexadecimal

Decimal

Description

Text Functions––continued

Set font ...............................

ESC @ F n

1B 40 46 n

27 64 70 n

This sequence selects any available font; it does not
change the current character spacing. Each font is

Courier ...........................

ESC @ F SOH

1B 40 46 01

27 64 70 1

assigned one or more numbers. To select a font, the
sequence must specify one of the assigned numbers.

Courier (alternate) .........

ESC @ F 1

1B 40 46 31

27 64 70 49

Downloaded fonts are assigned numbers in reverse order
beginning with FF hex (255 decimal). The list of

Gothic, 12 cpi ................

ESC @ F STX

1B 40 46 02

27 64 70 2

sequences to the left is only a partial list of font

Gothic, 12 cpi (alternate)

ESC @ F 2

1B 40 46 32

27 64 70 50

selections.

Gothic, 17.1 cpi .............

ESC @ F ETX

1B 40 46 03

27 64 70 3

Gothic, 17.1 cpi (alt.) ....

ESC @ F 3

1B 40 46 33

27 64 70 51

When the printer receives a sequence that selects a font

Trend PS ........................

ESC @ F EOT

1B 40 46 04

27 64 70 4

that is not in the installed Intelli-card(s), it sounds the

Trend PS (alternate) .......

ESC @ F 4

1B 40 46 34

27 64 70 52

audible alarm, displays the message FONT
UNAVAILABLE on the control panel, and continues

Elite ...............................

ESC @ F ENQ

1B 40 46 05

27 64 70 5

printing.

Orator ............................

ESC @ F BEL

1B 40 46 07

27 64 70 7

Courier Legal ................

ESC @ F HT

1B 40 46 09

27 64 70 9

Broadway .......................

ESC @ F FS

1B 40 46 1C

27 64 70 28

Micro ..............................

ESC @ F RS

1B 40 46 1E

27 64 70 30

Script ..............................

ESC @ F NAK

1B 40 46 15

27 64 70 21

Gothic PS .......................

ESC @ F ACK

1B 40 46 06

27 64 70 6

Micro PS ........................

ESC @ F '

1B 40 46 27

27 64 70 39

OCR-A ...........................

ESC @ F SP

1B 40 46 20

27 64 70 32

OCR-B ...........................

ESC @ F ETB

1B 40 46 17

27 64 70 23

APL ................................

ESC @ F EM

1B 40 46 19

27 64 70 25

General Scientific ...........

ESC @ F LF

1B 40 46 0A

27 64 70 10

DEC Scientific ...............

ESC @ F VT

1B 40 46 0B

27 64 70 11

Chemical ........................

ESC @ F CAN

1B 40 46 18

27 64 70 24

Download font 1 ............

ESC @ F 255

1B 40 46 FF

27 64 70 255

Download font 2 ............

ESC @ F 254

1B 40 46 FE

27 64 70 254

End extended character ....

ESC @ C

1B 40 43

27 64 67

This sequence ends the ECS mode by replacing the ECS

set mode

characters in the active font with the normal ASCII/IBM
characters designated by the SETS parameter on the
printer's Setup menu. ECS characters are assigned codes
above 7F hex. To restart the ECS mode, select the font
again using the Set Font sequence. If the active font is not
an ECS font, the printer ignores this sequence.
