TECHNICAL DATA
8
63
UFM 530 HT
www.krohne.com 12/2013 - 4002393201- HB UFM 530 HT R02 en
Installation conditions
Installation For detailed information refer to Installation on page 12.
Inlet run DN25...80: ≥ 50 DN
DN100...300: ≥ 15 DN
Outlet run DN25...80: ≥ 10 DN
DN100...300: ≥ 5 DN
Dimensions and weights For detailed information refer to Dimensions and weight on page 65.
Materials
Sensor Sensor Sensor Sensor
Sensor material Measuring tube (DN25...300): Stainless steel 1.4404 (AISI 316L)
Bundle wave guides: Stainless steel 1.4404 (AISI 316L)
Connection box: Die-cast aluminium (polyurethane coating)
Others materials on request
Process connections Process connections Process connections Process connections
Flange DN25...300: stainless steel 1.4404 (AISI 316L)
Others materials on request
Finish (measuring tube) No paint
Converter Converter Converter Converter
Housing material Standard: die-cast aluminum (polyurethane coated)
Option: stainless steel 1.4404 (AISI 316L)
Finish Standard: silver paint
Optional: offshore paint system, silver
Electrical connections
Description of used abbreviations Description of used abbreviations Description of used abbreviations Description of used abbreviations Q = XXX XXX XXX XXX
I
max
= maximal current
U
in
= XXX XXX XXX XXX
U
int
= internal voltage
U
ext
= external voltage
U
int, max
= maximal internal voltage
Galvanic insulation Galvanic insulation Galvanic insulation Galvanic insulation All inputs/outputs are standard isolated from the power supply.
Power supply Power supply Power supply Power supply
Voltage 100...240 VAC (+10% / -15%), 48...63 Hz.
24 VAC (20...27 V), 24 VDC (18...32 V).
Power consumption AC: 10 VA
DC: 8 W
Cable entries
(to power supply and sensor)
Standard: M20 x 1.5
Optional: ½" NPT or PF ½
Cable length Standard: 5 m / 16.40 ft
Optional: 10...30 m / 32.81...98.43 ft
