OPERATION
6
35
UFM 530 HT
www.krohne.com
12/2013 - 4002393201- HB UFM 530 HT R02 en
6.2 Available versions
All standard UFC 030 signal converters can be programmed in menu 3.02.01.
1. Standard version
1. Standard version
1. Standard version
1. Standard version
2. CORR T: on-site interchangeable to "standard".
2. CORR T: on-site interchangeable to "standard".
2. CORR T: on-site interchangeable to "standard".
2. CORR T: on-site interchangeable to "standard".
Temperature correction via analogue input 1 (temp range -50... +150°C) ; with this version the
outputs are non-Ex-I.
3. CORR T+P: on-site interchangeable to "standard".
3. CORR T+P: on-site interchangeable to "standard".
3. CORR T+P: on-site interchangeable to "standard".
3. CORR T+P: on-site interchangeable to "standard".
Temperature correction via analogue input 1, pressure correction via analogue input 2 (press
range 0...100 bar) ; with this version the outputs are Ex-I.
Corrected volume calculation can be done based on temperature correction or temperature -
and pressure correction.
The volume correction factor is based on API 2540; chapter 11.1 for the temperature correction
and chapter 11.2 for the pressure correction.
For liquid oil products the volume correction factors can be estimated as 0.1% per degree
Celsius and 0.01% per bar as a rule of thumb. Therefore for normal industrial processes these
corrections are hardly ever applied.
4. HEAT: on-site interchangeable to "standard".
4. HEAT: on-site interchangeable to "standard".
4. HEAT: on-site interchangeable to "standard".
4. HEAT: on-site interchangeable to "standard".
The UFC 030 signal converter is programmed for energy measurement, based on temperature
measurements connected via analogue inputs A1 and A2 (temperature range: -50...+150°C);
with this version the outputs are non-Ex-I. The following settings are needed:
INFORMATION!
The flowmeter is programmed at the factory according to your order. No changes are necessary.
No. of menu
Display text
Setting/description and functions
3.02.02
INP1 4mA
minimum value of temperature sensor 1 on inlet
3.02.03
INP1 20mA
maximum value of temperature sensor 1 on inlet
3.02.04
INP1 4mA
minimum value of temperature sensor 2 on outlet
3.02.05
INP1 20mA
maximum value of temperature sensor 2 on outlet
3.02.12
full scale
xxx (unit yyy)
3.03.02
function
totalizer
select direction
3.03.05
unit for total
energy
select unit
3.05.01
function pulse
output
CORR FLOW
3.05.10
pulse/unit
select unit
