6
OPERATION
48
UFM 530 HT
www.krohne.com 12/2013 - 4002393201- HB UFM 530 HT R02 en
4.05.01 PULS FUNCT Function of pulse output.
4.05.02 PULSE OUTP Unit of pulse output.
4.06.00, VOS (Velocity of sound)
Velocity of sound range incorrect. Note: ensure condition MAX VOS - MIN VOS ≥ 1 m/s (3.28 feet/s) is met!
4.06.01 MIN VOS Minimum velocity of sound.
4.06.02 MAX VOS Maximum velocity of sound.
4.07.00, PULSE OUTP (Pulse output)
Pulse output frequency value (f) incorrect. The maximum frequency is calculated from the PULSE/UNIT
setting and the maximum value of the measured value. Note: ensure condition
1 pulse/hr ≤ f ≤ 2000 pulse/s is met!
4.07.01 PULSE/UNIT Pulse value for volume flow rate unit.
4.07.02 PULSE/UNIT Pulse value for heat power rate unit.
4.08.00, PULS WIDTH
Pulse output pulse width incorrect. Note: ensure condition pulse width ≤ 0.5 x pulse period time is met!
4.08.01 PULS WIDTH Pulse width for frequencies ≤ 10 Hz.
4.09.00, HART
Current output range for HART ® incorrect. If HART ® is activated, the minimum possible current should
be 4 mA. Note: ensure condition CURR 0 pct ≥ 4 mA is met!
4.09.01 CURR RANGE Range of current output.
4.09.02 CURR = PCT Current value for 0% scale.
4.10.00, INP/OUTP (Input/Output)
The digital input (C) and current output (I) are not allowed to be switched on simultaneously. If the
Profibus option is activated, only one of the following input/output functions can be used: digital input (C),
current output (I), pulse output (P). The current output is deactivated by setting the function of current
output to "off" and setting the range of current output to 0...20 mA.
4.10.01 INP FUNCT Function of digital input.
4.10.02 CURR FUNCT Function of current output.
4.10.03 CURR RANGE Range of current output.
4.10.04 PULS FUNCT Range of pulse output.
4.13.00, EPROM
EPROM checksum error. Resetting device is necessary.
No. of menu Display text Setting/description and functions
