3-10
BOP HIPWR 080709
To change the background, press # from the power-up screen, Highlight Background, press
!
, highlight Black or White, then
$
to save. Press
$
exit and save for power-up or
%
to
apply the changes (without saving for power-up) and exit.
3.2.5.2 DISPLAYING PROGRAMMED SETTINGS IN REMOTE MODE
When Remote Debug is set to OFF (default), the programmed settings for main and protection
channels that are displayed on the LCD in local mode, are not displayed while in remote mode
and the LCD reads “Display settings off.” When set to ON, the programmed settings for main
and protection channels are displayed, however the unit responds more slowly in remote mode.
To change the Remote Debug setting, press # from the power-up screen (Figure 3-3), High-
light Remote Settings, press
!
, highlight On or Off, then
$
to save. Press
$
exit and save
for power-up or % to apply the changes (without saving for power-up) and exit.
3.2.5.3 ENABLING/DISABLING AUDIBLE BEEPS
From the power-up screen (Figure 3-3), press # , then refer to Table 3-3 and modify the setting
using the techniques described in PAR. 3.2.4). Even though audible beeps are set to off, the
beeps will still sound upon power-up or detection of a power supply fault.
TABLE 3-3. DISPLAY (OPERATOR CONVENIENCE) MENU FUNCTIONS
SETTING
CHOICES
(BOLD = Factory Default)
FUNCTION
NOTE: To save any of the functions listed below for power-up it is necessary to first change SAVE DISPLAY CHG at the password
setup (see PAR. 3.2.4.3and Figure 3-5) from DISABLE to ENABLE.
GRAPHIC DISPLAY Meters
75s Graph
30s Graph
15s Graph
7.5s Graph
3.8s Graph
1.5s Graph
0.8s Graph
0.5s Graph
0.3s Graph
0.15s Graph
0.04s Graph
0.08s Graph
METERS - Output voltage and current are displayed on representations of ana-
log meters.
GRAPH - Displays a sample of the output for the time indicated (see Figure 3-
4). The complete time-line uses 240 points. E.g., selecting 2 Second Graph
means that 2S/240 = 50ms sampling, i.e., every 50ms a snapshot of the output
state is used to produce a single point.
DISPLAY
BACKGROUND White
Black
WHITE - Sets the background to white and displays black characters.
BLACK - Sets the background to black and displays white characters.
REMOTE
DEBUG OFF
ON
OFF - LCD does not show programmed settings for main and protection chan-
nels while in remote mode of operation (local mode is unaffected).
ON - Programmed settings for main and protection channels are displayed,
however the unit responds more slowly.
KEY PRESS BEEP ON
ERROR ONLY
OFF
ON - provides an audible beep for each key press and for each error received.
ERROR ONLY - silences the beeps for each key press; errors will still cause
beep.
OFF - silences all beeps including key presses and errors except for power-up
and unit faults.
NOTE: Control display contrast by pressing
#
twice to dynamically change the contrast, then press
#
to set when contrast is
acceptable. Contrast can also be set directly by pressing
#
once and using
T
and
R
as needed (see PAR. 3.2.5.1).
