BOP HIPWR 080709
3-55
FIGURE 3-18. TREE DIAGRAM OF SCPI COMMANDS USED WITH BOP POWER SUPPLY (SHEET 2 OF 2)
3.6.3.8 STATUS SUBSYSTEM
This subsystem programs the power supply status register. The power supply has two groups of
status registers: Operation and Questionable. Each group consists of three registers: Condition,
Enable, and Event.
3.6.3.9 TRIGGER SUBSYSTEM
This subsystem controls the remote triggering of the power supply.
3.6.3.10 [SOURCE:]VOLTAGE AND [SOURCE:]CURRENT SUBSYSTEMS
These subsystems program the output voltage and current of the power supply.
[SOURce:] subsystem
[SOURce:]
VOLTage
[:LEVel]
[:IMMediate]
[:AMPLitude] val
[:AMPLitude]? MIN, MAX
:TRIGgered
[:AMPLitude] val
[:AMPLitude]?
:LIMit[:BOTH] "
[:BOTH]?
:NEGative
"
:NEGative?
:POSitive
"
:POSitive?
:MODE FIXed, LIST, TRANsient,
EXTernal, GAIN, PROTect
:MODE?
:PROTect
[:BOTH]
[:BOTH]?
:MODE INT, EXT, LESS
:MODE?
:NEGative
:NEGative?
:POSitive
:POSitive?
:LIM[:BOTH]
"
:LIM[:BOTH]?
:LIM:NEGative
"
:LIM:NEGative?
:LIM:POSitive
"
:LIM:POSitive?
ROOT : (colon)
[SOURce:]
CURRent
[:LEVel]
[:IMMediate]
[:AMPLitude] val
[:AMPLitude]? MIN, MAX
:TRIGgered
[:AMPLitude] val
[:AMPLitude]?
:LIMit[:BOTH] "
[:BOTH]?
:NEGative
"
:NEGative?
:POSitive
"
:POSitive?
:MODE FIXed, LIST, TRANsient,
EXTernal, GAIN, PROTect
:MODE?
:PROTect
[:BOTH]
[:BOTH]?
:MODE INT, EXT, LESS
:MODE?
:NEGative
:NEGative?
:POSitive
:POSitive?
:LIM[:BOTH]
"
:LIM[:BOTH]?
:LIM:NEGative
"
:LIM:NEGative?
:LIM:POSitive
"
:LIM:POSitive?
FUNCtion
:MODE VOLT, CURR, EXTernal
:MODE?
:TRIGger VOLTage, CURRent
:TRIGger?
LIST subsystem
LIST
:CLEar
:COUNt val
:COUNt?
:COUNt:SKIP int
:COUNt:SKIP?
:CURRent val,val
APPLy type,val1,val2,val3
SWEep START, STOP
SWEep?
:POINts?
:CURRent?
:DWELl val,val
:DWELl?
:POINts?
:QUERy val
:QUERy?
:REP val1,val2,val3
:RES?
:SAMP:CURRent int,val
:SAMP:VOLTage int,val
:SAMP?
:SET:SAMPle val
:SET:SAMPle?
:SET:TRIGger val ON, OFF
:SET:TRIGger?
:SET:WAIT val
:SET:WAIT?
:TRIGger val
:VOLTage val,val
APPLy type,val1,val2,val3
SWEep START, STOP
SWEep?
:POINts?
:VOLTage?
:WAIT
:HIGH val
:LEDG val
:LOW val
" Requires MEM:UPD to save for power-up.
