FIGURE 3-4. TREE DIAGRAM OF SCPI COMMANDS USED WITH BHK-MG 40W POWER SUPPLY
ABORt subsystem
ABORt
INITiate subsystem
INITiate
[:IMMediate]
:CONTinuous bool
:CONTinuous?
CALibrate subsystem
CALibrate
:STATe
:STATe?
:VOLTage
:LEVel (MIN | MAX | PROT)
[:DATA] val
GAIN (UP | DOWN)
:CURRent
:LEVel (MIN | MAX | MAG | PROT)
[:DATA] val
:ZERO
:SAVE
!
:COPY
:DUMP
:RESTore
MEASure subsystem
MEASure
[:SCALar]:CURRent[:DC]?
[:SCALar]:[VOLTage][:DC]?
OUTPut subsystem
OUTPut
[:STATe] ON | OFF or 0 | 1
[:STATe]?
DISPlay subsystem
DISPlay
:CONTrast 0.0 to 0.9
:CONTrast ?
:MODE
:MODE?
:TEXT
:TEXT?
ROOT :
(colon)
STATus subsystem
STATus
:OPERation
:CONDition?
:ENABle val
:ENABle?
[:EVENt]?
:PRESet
:QUEStionable
:CONDition?
:ENABle val
:ENABle?
[:EVENt]?
SYSTem subsystem
SYSTem
:BEEP
:COMM
:SER
:BAUD val!
:BAUD?
:ECHO!
:ECHO? ON, OFF
:PACE!
:PACE? NONE, XON
:PROMpt!
:PROMpt? ON, OFF
:GPIB:ADDR val
:GPIB:ADDR?
:ERRor
[:NEXT]?
:CODE?
[:NEXT]?
:ALL?
:GPIB:ADDR val
:GPIB:ADDR?
:KLOCk
:KLOCk?
:PASSword
[:CENAble] (code)
:STATe?
:CDISenable (code)
:NEW (OLD | NEW)
:SECUrity
:IMMediate
:VERSion?
INSTRument subsystem
INSTrument
:STATe?
:STATe (ON | OFF)
[SOURce:] subsystem
[SOURce:]
CURRent
[:LEVel]
[:IMMediate]
[:AMPLitude] val
[:AMPLitude]? MIN, MAX
:TRIGgered
[:AMPLitude] val
[:AMPLitude]? MIN, MAX
:LIMit
[:HIGH] val
!
[:HIGH]? MIN, MAX
:MODE LIST, FIX
:PROTection val
VOLTage
[:LEVel]
[:IMMediate]
[:AMPLitude] val
[:AMPLitude]? MIN, MAX
:TRIGgered
[:AMPLitude] val
[:AMPLitude]? MIN, MAX
:LIMit
[:HIGH] val
!
[:HIGH]? MIN, MAX
:MODE LIST, FIX
:PROTection val
FUNCtion
:MODE VOLTage CURRent
:MODE?
LIST subsystem
LIST
:CLE
:COUNT val
:COUN?
:COUN:SKIP val
:COUN:SKIP?
:CURRent
[:LEVel] val
[:LEVel]?
:POINter?
:DIR val
:DIR?
:DWELl val
:DWELl?
:POINter?
:DWELl
:QUERy val
:QUERy?
:VOLTage
[:LEVel] val
[:LEVel]?
:POINter?
TRIGGER subsystem
TRIGger
:SOURce
!
See PAR. 3.3.5.2 and Figure 3-2 for
special programming considerations.
