B-20
BHK-MG 1/2 (OPR) 121313
Description: Sending TRIG:SOUR activates either internal (BUS) or external (EXT) trigger. When the external trig-
ger (ground) is applied to J2 pin 3, output voltage and current are set to previously stored values for
VOLT:TRIG and CURR:TRIG.
NOTE: If INIT:CONT 1 was sent prior to sending TRIG:SOUR EXT, continuous mode is disabled and
unit will wait for INIT:IMM
TABLE B-4. ERROR MESSAGES
ERROR MESSAGE
ESR ERROR BIT SET
(SEE PAR. A.5)
EXPLANATION
0,“No error” None No error
-100,“Command error” Command Error bit 5 Command and data understood, but more information included which is
not recognized.
-102,”Syntax error” Command Error bit 5 First 4 characters recognized, subsequent characters not recognized.
-103,”Invalid separator” Command Error bit 5 For example, VOLT.PROT received instead of VOLT:PROT
-108,”Parameter Not
Allowed Error” Command Error bit 5 Volt12 sequence, channel number is invalid
-109,”Missing
parameter” Command Error bit 5 For example, VOLT instead of VOLT 21.
-111,”Header
separator error” Command Error bit 5 Missing space between volt and value or ; missing
-113,”Undefined
header” Command Error bit 5 First 4 characters could not be identified as legal command.For exam-
ple, command VLT instead of VOLT
-120,”Numeric data
error” Command Error bit 5 Expected number but other characters were detected
-121,”Invalid character
in number” Command Error bit 5 Volt 1,500 (comma not allowed)
-123,”Exponent too
large” Command Error bit 5 Exponent E+3 or greater is invalid.
-141,”Invalid character
data” Command Error bit 5 For example OUTP OFD or OUTP STOP instead of OUTP OFF
-150,”String data
error” Command Error bit 5 Invalid characters were detected in numeric entry.For example E.1
instead of E+1 or 4d3 instead of 4.3.
-203,”Command
protected” Execution error bit 4 Command only valid in password Cenable state
-221,”Settings
Conflict” Execution error bit 4 Invalid password from syst:pass:cen command
-222,“Data out of
range” Execution error bit 4 Value exceeds power supply rating
-223,”Data format
error” Execution error bit 4 Multiple decimals in digit, Multiple E, etc.
-224,“Illegal parameter
value” Execution error bit 4 For example, OUTP 2 instead of OUTP 1
-226,”Lists not Same
Length” Execution error bit 4 Dwell list does not match voltage or current list, or no points found for
voltage or current list.
-241,”Hardware
missing” Execution error bit 4 Requesting device 2 status (INST:NSEL 2)
