KEPCO BHK-MG 40W (Half Rack) Series - Manual (Page 140)

B-14
BHK-MG 1/2 (OPR) 121313
B.58 [SOURce:]FUNCtion:MODE? QUERY
FUNC:MODE?
Syntax: Short Form: FUNC:MODE? Long Form: [SOURce:]FUNCtion:MODE?
Return Value: VOLT or CURR
Description: Identifies the operating mode of the power supply. VOLT = Constant Voltage mode (CV).
CURR = Constant Current mode (CC). (See example, Figure B-1.)
FIGURE B-5. PROGRAMMING VOLTAGE
B.59 STATus:OPERation:CONDition? QUERY #$
STAT:OPER:COND?
Syntax: Short Form: STAT:OPER:COND? Long Form: STATus:OPERation:CONDition?
Return Value: 0 to 1313 (1 + 32 + 256 + 1024).
Description: Returns the value of the Operation Condition Register (see Table B-2). The Operation Condition
Register contains unlatched real-time information about the operating conditions of the power supply.
Bit set to 1 = function enabled (active, true); bit reset to 0 = function disabled (inactive, false). (See
example, Figure B-6.)
B.60 STATus:OPERation:ENABle COMMAND
STAT:OPER:ENAB
Syntax: Short Form: STAT:OPER:ENAB 0 to 1313 (1 + 32 + 256 + 1024)
Long Form: STATus:OPERation:ENABle 0 to 1313 (1 + 32 + 256 + 1024)
Description: Sets Operation Enable Register. The Operation Enable Register is a mask for enabling specific bits
in the Operation Event Register which will cause the operation summary bit (bit 7) of the Status Byte
register to be set. Bit set to 1 = function enabled (active, true); bit reset to 0 = function disabled (inac-
tive, false). The operation summary bit is the logical OR of all the enabled bits in the Operation Event
register. (See example, Figure B-6.)
NOTES: 1. The power supply is assumed to be operating in constant voltage (CV) mode.
2 Examples below are typical (using BHK 1000-40MG), intended only to illustrate command
functions. Refer to PAR. 3.6 for programming techniques to optimize performance.
OUTP ON Output enabled.
VOLT 218; CURR 1.1E-2 Power supply programmed to 218V, 0.011A.
VOLT 2.157E2
Power supply programmed to go to 215.7V.
VOLT? Returns 2.157E2, indicating programmed voltage = 215.7V.
VOLT? MAX For BHK 1000-40MG, returns 1000 (1000V).
VOLT? MIN Returns 0 (minimum allowable voltage).
VOLT:PROT 2.365E+2 Voltage protection set to 236.5V.
VOLT? Returns 2.157E+2, indicating programmed voltage value = 215.7V.
VOLT:PROT? Returns 2.365E+2, (programmed overvoltage protection = 236.5V
VOLT:PROT? MAX For BHK 1000-40MG, returns 1.1e+3 (1100V).
VOLT 221;CURR 1.1E-2 Power supply programmed to go to 221V, 0.011A.
VOLT?
Returns 221.
VOLT:LIM:HIGH 300 Voltage limit set to 300V.
VOLT:LIM:HIGH? Returns 300.
VOLT 333 Power supply not programmed to 333V., error message -222 posted.
VOLT? Returns 2.21e2.
TABLE B-2. OPERATION CONDITION REGISTER, OPERATION ENABLE REGISTER,
AND OPERATION EVENT REGISTER BITS
CONDITION NU CC NU CV NU WTG NU CAL
BIT 15-11 10 9 8 7 - 6 5 4 - 1 0
VALUE
32,768 -
2048
1024 512 256 128 - 64 32 16 -2 1
CAL - INTERFACE COMPUTING NEW CALIBRATION
CONSTANTS
CC - POWER SUPPLY IN CONSTANT CURRENT MODE
CV - POWER SUPPLY IN CONSTANT VOLTAGE MODE
NU - NOT USED
WTG WAIT FOR TRIGGER (SET BY INIT SUBSYSTEM)
