KEPCO BHK-MG 40W (Half Rack) Series - Manual (Page 21)

BHK-1/2-MG (OPR) 121313
1-5
OUTPUT CHARACTERISTICS (CONTINUED)
Series Connection Automatic or Master-Slave
Operation, limited by the d-c
isolation limit voltage For slave unit, use analog programming
only.
Parallel Connection Automatic or Master-Slave
Operation For slave unit, use analog programming
only.
GENERAL (ENVIRONMENTAL) CHARACTERISTICS
Temperature Operating 0° to +50° C
Storage -20° to +70° C
Humidity
0 to 95% RH
Non condensing
operating & storage
Shock 20g, 11msec ±50%
half sine
Non operating, 3-axes,
3 shocks each axis
Vibration 5-10Hz 10mm
double amplitude
Non operating, 3-axes,
1 hour each axis
Cooling Built-in fan, exhaust to rear
PHYSICAL CHARACTERISTICS
Dimensions See Figure 1-2.
Weight English 26 lbs. Unpacked
Metric 12 Kg
a-c source connections Front Circuit Breaker, 2-pole
Rear Detachable IEC 3-wire type
connector
d-c output terminals Rear panel Terminal Block (11 posi-
tions),
±Output, ±Sense, Ground, Internal
Capacitor (–), Grounding Network
Front panel Jacks (2) ±Output
Control Local: Digital control using front panel keypad(24 pads) and LCD
Remote: Digital control using rear panel IEEE 488 Bus (24 pin female connector).
Analog control using two rear panel terminal strips (10 positions) for
voltage and current
Digital display
front panel Voltage, current, mode, set-
tings, menu, program, etc. 2 x 16 character alphanumeric LCD with
LED backlight
TABLE 1-2. BHK-MG 40W SPECIFICATIONS (Continued)
SPECIFICATION RATING/DESCRIPTION CONDITION
