6 TECHNICAL DATA C520/C520X / R520/R520X
09/2010 • 86B5200001 www.inor.com 49
6.5 RTD and T/C accuracy table for C520/C520X / R520/R520X transmitters
CJC error not included.
Conformance level 95% (2 σ)
Input type Temp. range
Min
span
Accuracy
Max of: Temp. influence
(Dev. fr. ref.temp. 20°C)
RTD Pt100 -200…+850°C 10°C ±0.10°C or ±0.05% of span ±0.005% of span per K
RTD Pt1000 -200…+850°C 10°C ±0.10°C or ±0.05% of span ±0.005% of span per K
RTD PtX
Corr. to max.
4 k Ω
10°C ±0.10°C or ±0.05% of span ±0.005% of span per K
RTD Ni100 -60…+250°C 10°C ±0.10°C or ±0.05% of span ±0.005% of span per K
RTD Ni120 -60….+250°C 10°C ±0.10°C or ±0.05% of span ±0.005% of span per K
RTD Ni1000 -50…+180°C 10°C ±0.10°C or ±0.05% of span ±0.005% of span per K
RTD Cu10 -50…+260°C 83°C ±1.5°C or ±0.1% of span ±0.01% of span per K
T/C type B +400…+1800°C 700°C ±1°C or ±0.1% of span ±0.005% of span per K
T/C type C 0…+2315°C 200°C ±1°C or ±0.1% of span ±0.005% of span per K
T/C type D 0…+2315°C 200°C ±1°C or ±0.1% of span ±0.005% of span per K
T/C type E -200…+1000°C 50°C ±0.25°C or ±0.1% of span ±0.005% of span per K
T/C type J -200…+1000°C 50°C ±0.25°C or ±0.1% of span ±0.005% of span per K
T/C type K -200…+1350°C 50°C ±0.25°C or ±0.1% of span ±0.005% of span per K
T/C type N -100…+1300°C 100°C ±0.25°C or ±0.1% of span ±0.005% of span per K
T/C type N -250…+100°C 100°C ±1°C ±0.05% of span per K
T/C type R -50…+1750°C 300°C ±1°C or ±0.1% of span ±0.005% of span per K
T/C type S -50…+1750°C 300°C ±1°C or ±0.1% of span ±0.005% of span per K
T/C type T -200…+400°C 50°C ±0.25°C or ±0.1% of span ±0.005% of span per K
Table 22: RTD and T/C accuracy table for the C520/C520X / R520/R520X transmitters
