6 TECHNICAL DATA C520/C520X / R520/R520X
09/2010 • 86B5200001 www.inor.com 48
6.4.4 Output and input data
Table 20: Electrical data for outputs-inputs of R520X
6.4.5 Ambient temperature data for areas with potentially explosive atmospheres
Temperature class Ambient temperature
T6 -20°C ≤ T
a
≤ +60°C / -4°F ≤ T
a
≤ +140°F
T5 -20°C ≤ T
a
≤ +70°C / -4°F ≤ T
a
≤ +158°F
T4 -20°C ≤ T
a
≤ +70°C / -4°F ≤ T
a
≤ +158°F
Table 21: R520X temperature data
Output terminals 21, 22 Input terminals 1 to 8
U
i
= V
max
: ≤ 30 VDC U
o
= V
oc
: ≤ 6.6 VDC
I
i
= I
max
: ≤ 100 mA I
o
= I
sc
: ≤ 27.3 mA
P
i
=P
max
: ≤ 900 mW P
o
: ≤ 46 mW
L
i
: 10 µH L
o
: 25 mH
C
i
: 12.1 nF C
o
: 11 µF
