6 TECHNICAL DATA C520/C520X / R520/R520X
09/2010 • 86B5200001 www.inor.com 39
6.1.4 Output and input data
Output terminals 6, 7 Input terminals 1, 2, 3, 4, 5
U
i
= V
max
: ≤ 36 VDC U
o
= U
oc
: ≤ 3.3 VDC
I
i
= I
max
: - I
o
= I
sc
: ≤ 1.8 mA
P
i
= P
max
: - P
o
: ≤ 1.5 mW
L
i
: 10 µH L
o
: 25 mH
C
i
: 12.1 nF C
o
: 50 µF
Table 11: Output and input data, C520N
6.1.5 Ambient temperature data for areas with potentially explosive atmospheres
Temperature class Ambient temperature
T6 -40°C ≤ T
a
≤ +65°C / 40°F ≤ T
a
≤ +149°F
T5 -40°C ≤ T
a
≤ +80°C / 40°F ≤ T
a
≤ +176°F
T4 -40°C ≤ T
a
≤ +85°C / -40°F ≤ T
a
≤ +185°F
Table 12: Ambient temperature data, C520N
