6 TECHNICAL DATA C520/C520X / R520/R520X
09/2010 • 86B5200001 www.inor.com 45
6.3.4 Output and input data
Table 17: Output and input data, R520N
6.3.5 Ambient temperature data for areas with potentially explosive atmospheres
Temperature class Ambient temperature
T6 -20°C ≤ T
a
≤ +65°C / -4°F ≤ T
a
≤ +149°F
T5 -20°C ≤ T
a
≤ +70°C / -4°F ≤ T
a
≤ +158°F
T4 -20°C ≤ T
a
≤ +70°C / -4°F ≤ T
a
≤ +158°F
Table 18: Ambient temperature data, R520N
Output terminals 21, 22 Input terminals 1 to 8
U
i
= V
max
: ≤ 36 VDC U
o
= U
oc
: ≤ 3.3 VDC
I
i
= I
max
: - I
o
= I
sc
: ≤ 1.8 mA
P
i
= P
max
: - P
o
: ≤ 1.5 mW
L
i
: 10 µH L
o
: 25 mH
C
i
: 12.1 nF C
o
: 50 µF
