GENERAL INFORMATION
ICON Configuration Kit includes all necessary software and hardware for con-
figuration of all PC-programmable transmitters in the INOR product line from
a PC´s USB port, except for the Meso transmitters.
Configuration starts from the main program ConSoft.
ConSoft will identify the connected transmitter and open the necassary con-
figuration software.
ICON Configuration Kit consists of:
• USB Interface
• USB cable (connection between PC and USB Interface)
• Adapter cables (connection between USB Interface and transmitter)
• Software and drivers on a USB memory stick
Only one transmitter may be connected at a time.
The USB Interface is CE-marked and complies with the EMC-directive
2004/108/EC. For more information see the Declaration of Conformity.
ICON Configuration Kit is compatible with Windows 2000 (SP3), Windows XP
(SP2+), Windows Vista and Windows 7.
When installing, do not connect the USB Interface to your USB port
until prompted.
INOR USB Interface is a non Ex-approved product but is intended to
be used for all type of transmitters when in safe areas.
USER INSTRUCTIONS
The user instruction must be read prior to adjustment and/or installation.
All information subject to change without notice.
MEASURE OF SUCCESS
This product should not be mixed with other kind of scrap, after usage.
It should be handled as an electronic/electric device.
www.inor.com, www.inor.se
INOR Process AB, PO Box 9125, SE-200 39 Malmö, Sweden,
Phone: +46-40-31 25 60, Fax: +46-40-31 25 70, E-mail: [email protected]
INOR Transmitter OY, Unikkotie 13, FI-01300 Vantaa, Finland,
Phone: +358-10-421 7900, Fax: +358-10-421 7901, E-mail: [email protected]
INOR Transmitter GmbH, Am Bocksborn 5, D-63571 Gelnhausen, Germany,
Phone: +49-6051 14807, Fax:+49-6051 14806, E-mail: [email protected]
KROHNE Temperature Division INOR, 7 Dearborn Road, Peabody, MA 01960, USA
Phone: +1-978-826 6900, Fax:+1-978-535 3882, E-mail: [email protected]
DATA (shortform)
Input (PC to USB Interface)
USB cable
Output (USB Interface to
Changeable adapter cables
transmitter)
Power Supply
PC´s USB port, 5 VDC, 74 mA max
Ambient temperature
Operation
0 to 50 °C / 32 to 122 °F
Storage
-20 to 70 °C / -4 to 140 °F
Humidity (non-condensing)
0 to 90 %RH
Galvanic isolation
1500 VAC
USB compliance
USB v1.1 and USB v2.0
System requirements
Windows
Windows 2000 (SP3), XP (SP2+),
Vista or 7.
Display resolution
Minimum 800x600
Free hard disk space
50 MB
Ports
1 free USB port
INSTALLATION
INSTALLATION OF USB INTERFACE DRIVERS
Before you can use the USB Interface you must install USB drivers on your PC.
The memory stick contains the necessary USB drivers for the USB Interface.
Please refer to the guide “Installation Guide for ICON” (86BCONF004) for
installation instructions.
INSTALLATION OF CONFIGURATION SOFTWARE
All necessary software for configuration are included on the memory stick.
Please refer to the guide “Installation Guide for ICON” (86BCONF004) for
installation instructions.
All software, USB drivers and installation guides can also be downloaded from
the website www.inor.com
!
!
