The transmitters are delivered with either a factory settings or configured according to
customers’ specifications.
Menu
Designation
Parameter
Factory setting
Device Root menu
-> Sensors
-> Channel 1
Type of sensor 1
RTD Pt100
α=0.003850
Number of wires
4
PV Lower range value
0
PV Upper range value
100
Digital units
°C
Lock Code
Unlocked
Damping value
4 s
Line frequency
55
Isolation Resistance monitoring
Off
Sensor Break
(Off/Downscale/Upscale)
Upscale
Sensor Short circuit
(Off/Downscale/Upscale)
Upscale
Sensor Drift
(Off/Downscale/Upscale)
Off
-> Channel 2
Type of sensor 2
None
Number of wires
PV Lower range value
PV Upper range value
Digital units
°C
Lock Code
Unlocked
Damping value
4 s
Line frequency
55
Isolation Resistance monitoring
Off
Sensor Break
(Off/Downscale/Upscale)
Off
Sensor Short circuit
(Off/Downscale/Upscale)
Off
Sensor Drift
(Off/Downscale/Upscale)
Off
Table 3: The factory settings for C520/C520X / R520/R520X transmitters
