SOLAR300 - SOLAR300N
EN - 27
12/09/2006 – 16:55:10
WATTMETER12 – Page x/y
V12
I1
Patt12
Preatt12
Papp12
Pf12
CosPhi12
=
=
=
=
=
=
=
0.0 V
0.0 A
0 W
0 Var
0 VA
0.00i
0.00i
PAGE SCOPE HARM VECTORS
PARAMETERS CAPTION:
V12
 Phase L1 – Phase L2 voltage
I1  Current on L1 phase
Pact12  Active Power Wattmeter 12
Preact12  Reactive Power VARmeter 12
Papp12  Apparent Power VAmeter 12
Pf12  Power Factor Wattmeter 12
CosPhi12  Power Factor between fundamental of
 voltage and current Wattmeter 12
Fig. 45: Page of numerical values Wattmeter-Varmeter 1-2
12/09/2006 – 16:55:10
WATTMETER32 – Page 4/5
V32
I3
Patt32
Preatt32
Papp32
Pf32
CosPhi32
=
=
=
=
=
=
=
0.0
V
0.0
A
0 W
0
Var
0 VA
0.00i
0.00i
PAGE SCOPE HARM VECTORS
PARAMETERS CAPTION:
V32
 Phase L3 – Phase L2 voltage
I3  Current on L3 phase
Pact32  Active Power Wattmeter 32
Preact32  Reactive Power VARmeter 32
Papp32  Apparent Power VAmeter 32
Pf32  Power Factor Wattmeter 32
CosPhi32  Power Factor between fundamental of
 voltage and current Wattmeter 32
Fig. 46: Page of numerical values Wattmeter-Varmeter 3-2
12/09/2006 – 16:55:10
FLICKER – Page 5/5
V12 V23 V31
Pst1’ 0.0 0.0 0.0
Pst 0.0 0.0 0.0
Pst max 0.0 0.0 0.0
Plt 0.0 0.0 0.0
Plt max 0.0 0.0 0.0
Recording Time: 00h – 00min
PAGE SCOPE HARM VECTORS
PARAMETERS CAPTION:
Pst1’
 Short term severity after 1 minute
Pst  Short term severity
Pstmax  Maximum short term severity
Plt  Long term severity
Pltmax  Maximum long term severity
Recording Time  real time duration of recording
expressed in HH:MM
Fig. 47: Page of Flicker values
25/01/2013 – 16:55:10
TOT. ENERGY CONSUMPTION – Page x/y
Eact = 0 kWh
Ppeak = 0 kW
Date Ppeak : -- / -- / -- 00:00:00
Start rec. : -- / -- / -- 00:00:00
Stop rec. : -- / -- / -- 00:00:00
Rec. Time : - - -
Int. Per. : - - - Rec: - -
PAGE SCOPE HARM VECTORS
PARAMETERS CAPTION:
Eact
 Total active energy consumed when starting
recording.
Ppeak
 Maximum peak of consumed active power.
Date Ppeak  Date and time in which the peak occurred.
Start rec.  Date when recording was started.
Stop rec.  Date when recording was stopped.
Rec. Time  Time elapsed from Rec Start.
Int. Per.  Value of the set integration period.
Rec  Number of the recording in progress
Fig. 48: Consumed energy page
