SOLAR300 - SOLAR300N
EN - 25
12/09/2006 – 16:55:10
PHASE 2 RMS VALUES – Page 4/6
V2PE
I2
Patt2
Preatt2
Papp2
Pf2
CosPhi2
=
=
=
=
=
=
=
0.0 V
0.0 A
0 W
0 Var
0 VA
0.00i
0.00i
PAGE SCOPE HARM VECTORS
PARAMETERS CAPTION:
V2PE
 Phase L2-PE voltage
I2  Current on L2 phase
Pact2  Active Power L2 phase
Preact2  Reactive Power L2 phase
Papp2  Apparent Power L2 phase
Pf2  Power factor L2 phase
CosPhi2  Power factor between fundamental of
 voltage L2 and current L2
Fig. 39: Page numerical values of Phase 2
12/09/2006 – 16:55:10
PHASE 3 RMS VALUES – Page x/y
V3PE
I3
Patt3
Preatt3
Papp3
Pf3
CosPhi3
=
=
=
=
=
=
=
0.0 V
0.0 A
0 W
0 Var
0 VA
0.00i
0.00i
PAGE SCOPE HARM VECTORS
PARAMETERS CAPTION:
V3PE
 Phase L3-PE voltage
I3  Current on L3 phase
Pact3  Active Power L3 phase
Preact3  Reactive Power L3 phase
Papp3  Apparent Power L3 phase
Pf3  Power factor L3 phase
CosPhi3  Power factor between fundamental of
 voltage L3 and current L3
Fig. 40: Page numerical values of Phase 3
12/09/2006 – 16:55:10
FLICKER – Page x/y
V1PE V2PE V3PE
Pst1’ 0.0 0.0 0.0
Pst 0.0 0.0 0.0
Pst max 0.0 0.0 0.0
Plt 0.0 0.0 0.0
Plt max 0.0 0.0 0.0
Recording Time: 00h – 00min
PAGE SCOPE HARM VECTORS
PARAMETERS CAPTION:
Pst1’
 Short term severity after 1 minute
Pst  Short term severity
Pstmax  Maximum short term severity
Plt  Long term severity
Pltmax  Maximum long term severity
Recording Time  real time duration of recording
expressed in HH:MM
Fig. 41: Page of Flicker values
25/01/2013 – 16:55:10
TOT. ENERGY CONSUMPTION – Page x/y
Eact = 0 kWh
Ppeak = 0 kW
Date Ppeak : -- / -- / -- 00:00:00
Start rec. : -- / -- / -- 00:00:00
Stop rec. : -- / -- / -- 00:00:00
Rec. Time : - - -
Int. Per. : - - - Rec: - -
PAGE SCOPE HARM VECTORS
PARAMETERS CAPTION:
Eact
 Total active energy consumed when starting
recording.
Ppeak
 Maximum peak of consumed active power.
Date Ppeak  Date and time in which the peak occurred.
Start rec.  Date when recording was started.
Stop rec.  Date when recording was stopped.
Rec. Time  Time elapsed from Rec Start.
Int. Per.  Value of the set integration period.
Rec  Number of the recording in progress
Fig. 42: Consumed energy page
