Figure 11, Figure 12 – Agilent Technologies G6600-90006 User Manual
Page 49
Operation and Maintenance Manual
49
Figure 11 RV5 Oil-Sealed Vacuum Pump and Associated Traps (Front Side)
Figure 12 RV5 Oil-Sealed Vacuum Pump and Associated Traps (Back Side)
Oil mist
filter
Power switch
Mode selector
Edwards
EDWARDS
Oil return line
Chemical
Trap
Mounting
Bracket
Ballast control
Barbed Vacuum Inlet
Oil Mist
Filter
Chemical Trap
EDWARDS
5
Power
Plug
Ballast Control
Oil Return
Line
