Operation and Maintenance Manual 29
Figure 3 355 SCD Left Side
5 4
6
6
1. Ozone Generator
2. High Voltage Transformer
3. Photomultiplier Tube Socket
4. Photomultiplier Housing
5. Reaction Cell
6. Vacuum Line
7. Particulate Filter
8. Pre-Ozone Restrictor
9. Post-Ozone Restrictor
10. Pressure Transducer
8
7
9
10
1
2
3
