Chapter 3. Installing Production Monitoring™ Install the Latest Firmware
3.20 Production Monitoring™ User Manual IM8001
Procedure Details
update.
You can enter the IP address for the Welding
Power Source in one of two ways:
ƒ Type the specific IP address into the I
know the IP address of the welder field.
ƒ Choosing the I do not know the IP
address of the welder option. The
update utility scans your network and
displays a list of Welding Power Source
IP addresses on the same subnet.
NOTE | If this Welding Power Source has
older firmware, the IP address will not show up
using this method.
TIP | If you run into a problem, please refer to
the Troubleshooting section (Appendix B).
6. Click the Connect button once you have
entered the IP address for the power source
you are updating.
The software scans the Welding Power Source to
verify if the firmware currently on the machine is
up to date.
7. If the firmware is not up to date, you must click
Continue to update the Welding Power Source.
The system proceeds with the update.
If the firmware is already up to date, you will
receive the message Update not required and
you can click Exit to close the window.
