Viewing and editing switch encryption properties – Brocade Fabric OS Encryption Administrator’s Guide Supporting Key Management Interoperability Protocol (KMIP) Key-Compliant Environments (Supporting Fabric OS v7.1.0) User Manual
Page 140

122
Fabric OS Encryption Administrator’s Guide (KMIP)
53-1002747-02
Viewing and editing switch encryption properties
2
The Encryption Target Disk LUNs dialog box displays. The time left for auto rekey information is
listed in the table (
).
FIGURE 102
Encryption Targets Disk LUNs dialog box - Time left for auto rekey
Viewing and editing switch encryption properties
To view switch encryption properties, complete the following steps:
1. Select Configure > Encryption from the menu task bar to display the Encryption Center
dialog box. (Refer to
2. Select a switch or encryption engine from the Encryption Center Devices table, then select
Switch/Engine > Properties from the menu task bar, or right-click a switch or encryption engine
and select Properties.
NOTE
You can also select a group, switch, or engine from the Encryption Center Devices table, then
click the Properties icon.
The Encryption Switch Properties dialog box displays (
