Fabric OS Encryption Administrator’s Guide (KMIP)

111

53-1002747-02

Using the Encryption Targets dialog box

2

Using the Encryption Targets dialog box

The Encryption Targets dialog box enables you to send outbound data that you want to store as
ciphertext to an encryption device. The encryption target acts as a virtual target when receiving
data from a host, and as a virtual initiator when writing the encrypted data to storage.

NOTE

The Encryption Targets dialog box enables you to launch a variety of wizards and other related
dialog boxes.

To access the Encryption Targets dialog box, complete the following steps.

1. Select Configure > Encryption from the menu task bar to display the Encryption Center

dialog box (Refer to

Figure 6

on page 14).

2. Select a group, switch, or engine from the Encryption Center Devices table, then select

Group/Switch/Engine > Targets from the menu task bar.

NOTE

You can also select a group, switch, or engine from the Encryption Center Devices table, then
click the Targets icon.

The Encryption Targets dialog box displays (

Figure 95

). The targets currently being encrypted

by the selected group, switch, or encryption engine are listed. If a group is selected, all
configured targets in the group are displayed. If a switch is selected, all configured targets for
the switch are displayed.

FIGURE 95

Encryption Targets dialog box
