Sterling RT - Manual (Page 8)

7 SV01H
Technical Data
2.2 SMV Type Number Designation
The table herein describes the Type numbering designation for the SMVector Inverter models.
ESV 152 N0 2 T X B
Electrical Products in the SMVector Series
Power Rating in kW:
251 = 0.25kW (0.33HP) 113 = 11.0kW (15HP)
371 = 0.37kW (0.5HP) 153 = 15.0kW (20HP)
751 = 0.75kW (1HP) 183 = 18.5kW (25HP)
112 = 1.1kW (1.5HP) 223 = 22.0kW (30HP)
152 = 1.5kW (2HP)
222 = 2.2kW (3HP)
302 = 3.0kW (4HP)
402 = 4.0kW (5HP)
552 = 5.5kW (7.5HP)
752 = 7.5kW (10HP)
Installed I/O & Communication Module(s):
C_ = CANopen (Available all models) The “_” blank can be:
D_ = DeviceNet (Available all models) 0 = Standard Keypad
E_ = Ethernet/IP, ModBus TCP/IP (Avail all models) N = No Keypad (NEMA 4X / IP65 only)
R_ = RS-485 / ModBus /Lecom (Avail all models)
P_ = ProfiBus-DP (Available all models)
N_ = No Communications installed (Non-IP20)
Input Voltage:
1 = 120 VAC (doubler output) or 240 VAC
2 = 240 VAC
4 = 400/480 VAC
6 = 600 VAC
Input Phase:
S = Single Phase Input only
Y = Single or Three Phase Input
T = Three Phase Input only
Input Line Filter
F = Integral EMC Filter
L = Integral EMC Filter and Integrated Disconnect Switch (NEMA 4X/IP65 Models only)
M = Integrated Disconnect Switch (NEMA 4X/IP65 Models only)
X = No EMC Filter/ No Disconnect Switch
Enclosure:
B = NEMA 1/IP31; Indoor only
C = NEMA 4X/IP65; Indoor only; Convection cooled
D = NEMA 4X/IP65; Indoor only; Fan cooled
E = NEMA 4X/IP65; Indoor/Outdoor; Convection cooled
F = NEMA 4X/IP65; Indoor/Outdoor; Fan cooled
NOTE
Prior to installation make sure the enclosure is suitable for the end-use environment
Variables that influence enclosure suitability include (but are not limited to) temperature, airborne
contaminates, chemical concentration, mechanical stress and duration of exposure (sunlight,
wind, precipitation)
.
