Technical Data
240V Three Phase (3/PE) (170...264V); 48...62Hz
Type
Power
Mains Current
Output Current
Heat Loss (Watts)
Hp
kW
240V
A
Cont (I
n
)
A
Max I
%
N1/IP31
N4X/IP65
No filter
N4X/IP65
W/ filter
ESV112--2T--
1.5
1.1
6.9
6
200
64
ESV152--2T--
2
1.5
8.1
7
200
75
ESV222--2T--
3
2.2
10.8
9.6
200
103
ESV402--2T--
5
4.0
18.6
16.5
200
154
139
ESV552--2T--
7.5
5.5
26
23
200
225
167
ESV752--2T--
10
7.5
33
29
200
274
242
ESV113--2T--
15
11
48
42
180
485
468
ESV153--2T--
20
15
59
54
180
614
591
NOTES:
Output Current: The Output Current Maximum (%) is a percentage of the Output Current Continuous Amps (In) rating
and is adjustable in parameter P171.
400...480VAC Models
400 ... 480V Three Phase (3/PE) (400V: 340...440V), (480V: 340...528V); 48...62Hz
Type
Power
Mains Current
Output Current
Heat Loss (Watts)
Hp
kW
400V
A
480V
A
Cont (I
n
)
A
Max I
%
N1/IP31
N4X/IP65
No filter
N4X/IP65
W/ filter
400V 480V
400V
480V
ESV371--4T--
0.5
0.37
1.7
1.5
1.3 1.1 175 200
23
21
25
ESV751--4T--
1
0.75
2.9
2.5
2.4 2.1 175 200
37
33
37
ESV112--4T--
1.5
1.1
4.2
3.6
3.5 3.0 175 200
48
42
46
ESV152--4T--
2
1.5
4.7
4.1
4.0 3.5 175 200
57
50
54
ESV222--4T--
3
2.2
6.1
5.4
5.5 4.8 175 200
87
78
82
ESV302--4T--
4
3.0
8.3
7.0
7.6 6.3 175 200
95
ESV402--4T--
5
4.0
10.6
9.3
9.4 8.2 175 200
128
103
111
ESV552--4T--
7.5
5.5
14.2
12.4
12.6 11.0 175 200
178
157
165
ESV752--4T--
10
7.5
18.1
15.8
16.1 14.0 175 200
208
190
198
ESV113--4T--
15
11
27
24
24
21
155 180
418
388
398
ESV153--4T--
20
15
35
31
31
27
155 180
493
449
459
ESV183--4T--
25
18.5
44
38
39
34
155 180
645
589
600
ESV223--4T--
30
22
52
45
46
40
155 180
709
637
647
NOTES:
Output Current: The Output Current Maximum (%) is a percentage of the Output Current Continuous Amps (In) rating
and is adjustable in parameter P171.
For 400...480 VAC models, the output current maximum (%) in the 400V column is used when P107 = 0
For 400...480 VAC models, the output current maximum (%) in the 480V column is used when P107 = 1
