Sterling RT - Manual (Page 30)

29 SV01H
Commissioning
Code Possible Settings
IMPORTANT
No. Name Default Selection
p 0 Relay Output
TB-16, 17 0 0 None Disables the output
1 Run Energizes when the drive is running
2 Reverse Energizes when reverse rotation is active
3 Fault De-energizes when the drive trips, or power
is removed
4 Inverse Fault Energizes when the drive trips
5 Fault Lockout P110 = 3...6: De-energizes if all restart
attempts fail
6 At Speed Energizes when output frequency =
commanded frequency
7 Above Preset Speed #6 Energizes when output frequency > P136
8 Current Limit Energizes when motor current = P171
9 Follower Loss (4-20 mA) Energizes when 4-20 mA signal falls below
2 mA
10 Loss of Load Energizes when motor load drops below P145;
Refer to P146 also
11 Local Keypad Control Active
Energizes when the selected source is active
for start control
12 Terminal Strip Control Active
13 Remote Keypad Control Active
14 Network Control Active
15 Standard Reference Active
Energizes when P101 reference is active
16 Auto Reference Active Energizes when Auto Reference is activated
using TB-13 input; refer to P121...P124
17 Sleep Mode Active Refer to P240...P242
18 PID Feedback < Min. Alarm Energizes when PID feedback signal < P214
19 Inverse PID Feedback < Min. Alarm De-energizes when PID feedback
signal < P214
20 PID Feedback > Max Alarm Energizes when PID feedback
signal > P215
21 Inverse PID Feedback > Max Alarm De-energizes when PID feedback signal >
P215
22 PID Feedback within
Min/Max Alarm range
Energizes when PID feedback signal is within
the Min/Max Alarm range; refer to P214, P215
23 PID Feedback outside
Min/Max Alarm range
Energizes when PID feedback signal is outside
the Min/Max Alarm range; refer to P214, P215
24 Reserved
25 Network Activated
Requires optional communication module
(refer to the network module documentation).
TB-14 Output 0 0...23 (same as P140)
24 Dynamic Braking
For use with Dynamic Braking option
25 Network Activated Requires optional communication module
(refer to the network module documentation).
