Yokogawa Data Acquisition with PID Control CX2000 User Manual
Page 54
8-2
IM 04L31A01-01E
Note
•
A gasket is attached to the edge of the case. When reinstalling the bezel, be sure that the
gasket is correctly fastened.
•
A lever is attached to the right side of the bezel. By hooking the lever onto the side of the
case, you can lock the bezel in the open position.
Lever
•
The power switch is located in the upper left as you are facing the instrument. When this
switch is turned OFF, it prevents power from being supplied to the instrument even when
the power cord is connected. Therefore be sure to turn the power switch ON before you
reassemble the instrument.
Power Switch
8.1 Removing the Bezel
