3-2 SM 04L31A01-01E
Calibrating the Input Range
For each group, input the zero and full scale for the input range to the channels below
and perform calibration.
CX1000
• Voltage Range
Control
Number of Internal Group 2 (1—5ch)
Control Loops Zero Full Scale
0 loops — —
2 loops CH1* CH2*
* The expression channel is not used for control input, but for expediency the inputs are
referred to (from right to left) as CH1 and CH2 respectively.
Monitor
No. of Inputs for Meas. Group 1 (1—6ch)
Zero Full Scale Zero Full Scale
6ch CH1 CH2
• RTD Range
Control
Number of Internal Group 2 (1—5ch)
Control Loops 100 Ω 300 Ω
0 loops — —
2 loops CH1* CH2*
* The expression channel is not used for control input, but for expediency the inputs are
referred to (from right to left) as CH1 and CH2 respectively.
Monitor
No. of Measurement Group 1 (1—6ch)
Input Channels 100 Ω 300 Ω
6ch CH1 CH2
CX2000
• Voltage Range
Control (1st Slot)
Number of Internal Group 1 Group 2
Control Loops Zero Full Scale Zero Full Scale
0 loops — — — —
2 loops CH1 CH2 — —
Loops 4,6 CH1 CH2 CH6 CH7
Monitor (2nd, 3rd Slot)
No. of Inputs for Meas. Group 1 Group 2
Zero Full Scale Zero Full Scale
10 ch CH1 CH2 — —
20 ch CH1 CH2 CH11 CH12
3.1 Calibration of the Measuring Instrument's Input
