Page 33
SM 04L05A01-01E
5-2
5.2
Flow Chart
This flow chart consists of general service operations when a fault occurs. This chart is
not always suitable for every kind of fault. However, it is recommended to perform
operations according to the flow chart.
START
END
YES
YES
NO
NO
Phenomenon check
Cause check
Assembly exchange and
adjustment
Performance test execution
Repaired?
