8-1
IM 04L31A01-01E
Procedures for Disassembly (CX1000)
8
Chapter 8 Procedures for Disassembly (CX1000)
8.1 Removing the Bezel
WARNING
The service manual is to be used by properly trained personnel only. To avoid
personal injury, do not perform any servicing unless you are qualified to do so.
Refer to the safety precautions prior to performing any servicing. Even if
servicing is carried out according to this service manual, or by qualified
personnel, YOKOGAWA assumes no responsibility for any result occurring from
that servicing.
CAUTION
If removing the assembly, be sure to disconnect the power cable from the outlet
before doing so.
Opening the Bezel
1. Open the Key Case Assembly then remove the two screws as shown.
2. The Bezel hooks on to holes in the top of the case. Pull the bottom of the bezel
outward slightly, lift the entire bezel upwards to release it from the case, then
swing the bottom of the bezel upwards to open it.
