Yokogawa Touch Screen GP20 - Manual (Page 37)

2-23
IM 04L51B01-17EN
Commands and Responses
1
2
App
SAlmMarkMath,015,On,Fixed,255,0,0,
165,42,42,255,165,0,255,255,0
Description
• For details on RGB values, see “Description” of the
SColorIO command.
SRangeCom
Measurement Range (/MC)
Sets the measurement range of a communication
channel.
Unused Channels
Syntax SRangeCom,p1,p2
p1 Channel number
p2 Enable or disable (Off)
Used Channels
Syntax SRangeCom,p1,p2,p3,p4,p5,p6
p1 Channel number
p2 Enable or disable (On)
p3 Decimal Place (0 to 5)
P4 Span lower limit (-9999999 to 99999999)
p5 Span upper limit (-9999999 to 99999999)
p6 Unit (up to 6 characters, UTF-8)
Query SRangeCom[,p1]?
Example Measure 0.00 to 100.00% on communication
channel 025.
SRangeCom,025,On,2,0,10000,’%’
Description
• You cannot use this command to configure settings
while recording is in progress.
• You cannot use this command to configure settings
while computation is in progress.
• If p2=Off, you cannot set p3 or subsequent
parameters.
• You cannot set the span upper and lower limits to the
same value.
SValueCom
Preset Operation (/MC)
Sets the preset operation of a communication channel.
Syntax SValueCom,p1,p2,p3
p1 Channel number
p2 Value at power-on (Preset, Last)
p3 Preset value (–9.999999E+29 to –1E–30,
0, 1E–30 to 9.999999E+29)
Query SValueCom[,p1]?
Example At power-on, replace the communication
channel 025 value with the preset value of 0.5.
SValueCom,025,Preset,0.5
SWDCom
Watchdog Timer (/MC)
Sets the watchdog timer of a communication channel.
Channels That Do Not Use Watchdog Timers
Syntax SWDCom,p1,p2
p1 Channel number
p2 Watchdog timer usage (Off)
Channels That Use Watchdog Timers
Syntax SWDCom,p1,p2,p3,p4
p1 Channel number
p2 Watchdog timer usage (On)
2.4 Setting Commands
