TURCK Modular Industrial I/O System BL 67
Electrical: • Operating Current: <30 mA from V
MB
• Output Current: <10 A for downstream I/O
Power Distribution: • Accepts 24 VDC supply to provide V
1
and V
O
for downstream modules
Material: • Connectors: Nickel-plated brass
• Housing: PC-V0 (Lexan)
Diagnostics (Logical): • Diagnostic information available through the fieldbus gateway
Diagnostics (Physical): • LED to indicate module bus communication status as well as I/O diagnostics
• LEDs for each I/O point to indicate on/off status
BL67-PF-24VDC
3.583
(91.0)
1.654 (42.0)
Diagnostic
LEDs
Status
LEDs
Power
Connectors
1.260 (32.0)
5.709
(145.0)
Pinouts
Male
4-Pin
Male
5-Pin
1 = V
O
, V
I
2 = NC
3 = NC
4 = Gnd
1 = Gnd
2 = Gnd
3 = PE
4 = V
I
5 = V
O
minifast ® Pinouts minifast ® Pinouts
1
5
4
3
2 1
4
3
2
Power Feeding Module
When used with BL67-B-1RSM base module. When used with BL67-B-1RSM-4 base module.
Modular I/O
•
Fieldbus Independent Configuration
•
IP 67 Protection
•
Various I/O Styles
