TURCK Modular Industrial I/O System BL 67
4 Discrete Input Modules
Electrical:
•
Operating Current: <30 mA from V
MB
<40 mA from V
I
(...-P)
<1 mA from V
I
(...-N)
Power Distribution:
•
Inputs: V
I
•
Logic: V
MB
and V
I
Material:
•
Connectors: Nickel-plated brass
•
Housing: PC-VO (Lexan)
Diagnostics (Logical):
•
Diagnostic information available through the fieldbus gateway
Diagnostics (Physical):
•
LED to indicate module bus communication status as well as I/O diagnostics
•
LEDs for each I/O point to indicate on/off status
BL67-4DI-P
BL67-4DI-N
D
A
B
C
5.709
(145.0)
3.583
(91.0)
1.654 (42.0)
Diagnostic
LEDs
I/O LEDs
I/O
Connector
1.260 (32.0)
BL67
7.677
(195.0)
BL67
BL67
BL67
D
D
D
D
Inputs
Data
Part Number
Drawing
Input
Count
Connectors
Pinout
Inputs per
Connector
Sensor
Style
Group
Diagnostics
Individual
Diagnostics
Wire-Break
Detection
I/O
Map
BL67-4DI-P with BL67-B-4M12*
A
4
0-3
S
1
PNP
X
1
BL67-4DI-P with BL67-B-2M12*
B
4
0-1
2S
2
PNP
X
1
BL67-4DI-P with BL67-B-2M12-P*
B
4
0-1
2S
2
PNP
X
1
BL67-4DI-P with BL67-B-4M8*
D
4
0-3
PI
1
PNP
X
1
BL67-4DI-P with BL67-B-1M23*
C
4
0
M23-4I
4
PNP
X
1
BL67-4DI-N with BL67-B-4M12*
A
4
0-3
S
1
NPN
X
1
BL67-4DI-N with BL67-B-2M12*
B
4
0-1
2N
2
NPN
X
1
BL67-4DI-N with BL67-B-2M12-P*
B
4
0-1
2N
2
NPN
X
1
BL67-4DI-N with BL67-B-4M8*
D
4
0-3
PI
1
NPN
X
1
BL67-4DI-N with BL67-B-1M23*
C
4
0
M23-4I
4
NPN
X
1
2S
Mating cordset: RK 4.4T-*-RS 4.4T
Splitter: VBRS 4.4-2RK 4T-*/*
2N
Mating cordset: RK 4.5T-*-RS 4.5T
PI
Mating cordset: PSG 3M-*
S
Mating cordset: RK 4.4T-*-RS 4.4T
BU
BK
BN
BU
BK
BN
V-
PE
Input
V
I
+
WH
Input (B)
V-(A&B)
PE
Input (A)
V
I
+(A&B)
BU
BK
BN
WH
Input (B)
V-(A&B)
PE
Input (A)
V
I
+(A&B)
BU
BK
BN
V-
Input
V
I
+
1
2
3
4
5
1
2
3
4
5
1
2
3
4
5
1
3
4
M23-4I
1 = Input
1
2 = Input
2
3 = Input
3
4 = Input
4
5 = NC
6 = NC
7 = NC
8 = NC
9 = V
I
+
10 = V
I
+
11 = V
I
+
12 = V-
1
4
3
5
2
6
7
8
9
10
11
12
Out
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
n-1
(Data for modules to the left)
n
Data for next discrete modules
I-1
I-2
I-3
I-0
n+1
(Data for modules to the right)
Input Connectors
I/O Data Map 1
Shown with
BL67-B-4MB base
Modular I/O
•
Fieldbus Independent Configuration
•
IP 67 Protection
•
Various I/O Styles
