TURCK Modular Industrial I/O System BL 67
Electrical:
•
Operating Current: <140 mA from V
MB
(RS232)
<60 mA from V
MB
(RS485/422)
<50 mA from V
MB
(SSI)
<50 mA from V
(all)
Power Distribution:
•
Inputs: V
•
Logic: V
MB
and V
Material:
•
Connectors: Nickel-plated brass
•
Housing: PC-VO (Lexan)
Diagnostics (Logical):
•
Diagnostic information available through the fieldbus gateway
Diagnostics (Physical):
•
LED to indicate module bus communication status as well as I/O diagnostics
•
LEDs for each I/O point to indicate on/off status
BL67-1RS485/422
BL67-1RS232
BL67-1SSI
C
B
A
3.583
(91.0)
1.654 (42.0)
1.260 (32.0)
5.709
(145.0)
Diagnostic
LEDs
I/O LEDs
I/O
Connectors
Diagnostic
LEDs
I/O
LEDs
I/O
Connectors
Serial Communication Modules
Inputs
Outputs
Data
Part Number
Dra
wing
Input Count
Connector
s
Pinout
Inputs per
Connector
Sensor
Style
Gr
oups
Dia
gnostics
Output
Count
Connector
s
Pinout
Outputs per
Connector
s
I/O
Map
BL67-1RS485/422 with BL67-B-1M12*
A
1
0
B4
1
RS 485/422
X
0
B4
1
1
1
BL67-1RS485/422 with BL67-B-1M12-8*
B
1
0
B4-8
1
RS 485/422
X
0
B4-8
1
1
1
BL67-1RS232 with BL67-B-1M12*
A
1
0
B2
1
RS 232
X
0
B2
1
1
1
BL67-1RS232 with BL67-B-1M12-8*
B
1
0
B2-8
1
RS 232
X
0
B2-8
1
1
1
BL67-1SSI with BL67-B-1M23*
C
1
0
SSI-23
1
SSI
X
0
SSI-23
1
2
2
BL67-1SSI with BL67-B-1M12-8*
B
1
0
SSI
1
SSI
X
0
SSI
1
2
2
Modular I/O
•
Fieldbus Independent Configuration
•
IP 67 Protection
•
Various I/O Styles
