TURCK Modular Industrial I/O System BL 67
8 Discrete Input Modules
Electrical:
•
Operating Current: <30 mA from V
MB
<40 mA from V
I
(...-P)
<1 mA from V
I
(...-N)
Power Distribution:
•
Inputs: V
I
•
Logic: V
MB
Mechanical:
•
Operating Temperature: 0 to +55°C (+32 to +131°F)
•
Protection: NEMA 1,3,4,12,13 / IEC IP 67
•
Vibration: 5 g @ 10-500 Hz
Material:
•
Connectors: Nickel-plated brass
•
Housing: PC-VO (Lexan)
Diagnostics (Logical):
•
Diagnostic information available through the fieldbus gateway
Diagnostics (Physical):
•
LED to indicate module bus communication status as well as I/O
diagnostics
•
LEDs for each I/O point to indicate on/off status
BL67-8DI-P
BL67-8DI-N
D
A
B
C
3.583
(91.0)
1.654 (42.0)
Diagnostic
LEDs
I/O LEDs
I/O
Connector
1.260 (32.0)
7.677
(195.0)
Inputs
Data
Part Number
Drawing
Input
Count
Connectors
Pinout
Inputs per
Connector
Sensor
Style
Group
Diagnostics
Individual
Diagnostics
Wire-Break
Detection
I/O
Map
BL67-8DI-P with BL67-B-4M12*
A
8
0-3
2S
2
PNP
X
1
BL67-8DI-P with BL67-B-4M12-P*
B
8
0-3
2S
2
PNP
X
1
BL67-8DI-P with BL67-B-8M8*
B
8
0-7
PI
1
PNP
X
1
BL67-8DI-P with BL67-B-1M23
D
8
0
M23-8I
8
PNP
X
1
BL67-8DI-N with BL67-B-4M12*
A
8
0-3
2N
2
PNP
X
1
BL67-8DI-N with BL67-B-4M12-P*
B
8
0-3
2N
2
NPN
X
1
BL67-8DI-N with BL67-B-8M8*
C
8
0-7
PI
1
NPN
X
1
BL67-8DI-N with BL67-B-1M23
D
8
0
M23-8I
NPN
X
1
M23-8I
1 = Input
0
2 = Input
1
3 = Input
2
4 = Input
3
5 = Input
4
6 = Input
5
7 = Input
6
8 = Input
7
9 = V
I
+
10 = V
I
+
11 = V
I
+
12 = V-
1
4
3
5
2
6
7
8
9
10
11
12
In
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
n-1
(Data for modules to the left)
n
I-7
I-6
I-5
I-4
I-3
I-2
I-1
I-0
n+1
(Data for modules to the right)
Input Connectors
2S
Mating cordset: RK 4.4T-*-RS 4.4T
Splitter: VBRS 4.4-2RK 4T-*/*
2N
Mating cordset: RK 4.5T-*-RS 4.5T
PI
Mating cordset: PSG 3M-*
I/O Data Map 1
Application:
TURCK splitter box: 8MB12Z-4PZ-CS12
Cable: CSWM CKWM 12-10-*/S101/BL67
Shown with
BL67-B-4M12 base
Modular I/O
•
Fieldbus Independent Configuration
•
IP 67 Protection
•
Various I/O Styles
