TURCK Modular Industrial I/O System BL 67
Electrical: • Operating Current: <60 mA from V
MB
(V)
<40 mA from V
MB
(I)
<50 mA from V
I
(all)
Power Distribution: • Inputs: V
I
• Logic: V
MB
and V
I
Material: • Connectors: Nickel-plated brass
• Housing: PC-V0 (Lexan)
Diagnostics (Logical): • Diagnostic information available through the fieldbus gateway
Diagnostics (Physical): • LED to indicate module bus communication status as well as I/O diagnostics
• LEDs for each I/O point to indicate on/off status
BL67-2AO-V
BL67-2AO-I
3.583
(91.0)
1.654 (42.0)
Diagnostic
LEDs
I/O LEDs
I/O
Connectors
1.260 (32.0)
5.709
(145.0)
Input Connectors
B-AOV
Out
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
n-1 (Data from modules to the left)
n Channel 0, LSB
n+1 Channel 0, MSB
n+2 Channel 1, LSB
n+3 Channel 1, MSB
n+4 (Data from modules to the right)
2 Analog Output Modules
Mating cordset:
RK 4.5T-*-RS 4.5T
Mating cordset:
RK 4.5T-*-RS 4.5T
Outputs Data
Part Number
Output
Count
Connectors Pinout
Outputs per
Connector
Type
Individual
Diagnostics
Wire-Break
Detection
I/O Map
BL67-2AO-V with BL67-B-2M12* 2 0-1 B-AOV 1 -10/0 to 10V 1
BL67-2AO-I with BL67-B-2M12* 2 0-1 B-AOI 1 0/4 to 20 mA 1
B-AOI
