TURCK Modular Industrial I/O System BL 67
Deluxe 4 Discrete Input
4 Discrete Output Module
Electrical:
•
Operating Current: <30 mA from V
MB
<100 mA from V
O
•
Output Current: <0.5 A per output from V
O
Power Distribution:
•
Inputs: V
O
•
Logic: V
MB
and V
O
Material:
•
Connectors: Nickel-plated brass
•
Housing: PC-VO (Lexan)
Diagnostics (Logical):
•
Diagnostic information available through the fieldbus gateway
Diagnostics (Physical):
•
LED to indicate module bus communication status as well
as I/O diagnostics
•
LEDs for each I/O point to indicate on/off status
BL67-4DI4DO-PD
D
B
A
C
3.583
(91.0)
1.654 (42.0)
1.260 (32.0)
7.677
(195.0)
Diagnostic
LEDs
I/O LEDs
I/O
Connectors
Diagnostic
LEDs
I/O
LEDs
I/O
Connectors
Inputs
Outputs
Data
Part Number
Dra
wing
Input Count
Connector
s
Pinout
Inputs per
Connector
Sensor
Style
V
I
+ A
v
ail.
Current
Gr
oup
Dia
gnostics
Individual
Wire-Break
Detection
Output Count
Connector
s
Pinout
Outputs per
Connector
Current
Individual
Dia
gnostics
Wire-Break
Detection
I/O Map
BL67-4DI4DO-PDwith BL67-B-4M12-P* A
4
0-1
2S
2
PNP
X
4
2-3
2G
2
0.5 A
X
1
BL67-4DI4DO-PD with BL67-B-4M12*
B
4
0-3
C
1
PNP
X
4
0-3
C
1
0.5 A
X
1
BL67-4DI4DO-PD with BL67-B-8M8*
C
4
0-3
PI
1
PNP
X
4
4-7
PO
1
0.5 A
X
1
BL67-4DI4DO-PD with BL67-B-1M23*
D
4
0
M23
4
PNP 80 mA each
4
0
M23
4
0.5 A
1
BL67-4DI4DO-PD with BL67-B-1M23*
D
4
0
M23
4
PNP
4 a total
4
0
M23
4
0.5 A
M23
1 = Input
0
2 = Input
1
3 = Input
2
4 = Input
3
5 = Output
0
6 = Output
1
7 = Output
2
8 = Output
3
9 = V
I
+
10 = V
I
+
11 = V
I
+
12 = V-
Shown with
BL67-B-4M12 base
Input/Output Connectors
PI
Mating cordset: PSG 3M-*
2S
Mating cordset:
RK 4.4T-*-RS 4.4T
Splitter: VBRS 4.4-2RK 4T-*/*
2G
Mating cordset:
RK 4.4T-*-RS 4.4T
Splitter: VBRS 4.4-2RK 4T-*/*
C
Mating cordset:
RK 4.4T-*-RS 4.4T
Splitter:
VB2-RS 4.4T-1/2RK 4.4T-*/*/S651
I/O Data Map 1
Note: I/O faults can be reported in the I/O map. Consult the product user
manual for details.
In
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1 Bit 0
n-1
(Data for modules to the left)
n
Data for next discrete modules
I-3
I-2
I-1
I-0
n+1
(Data for modules to the right)
Out
n-1
(Data for modules to the left)
n
Data for next discrete modules
0-3
0-2
0-1
0-0
n+1
(Data for modules to the right)
Modular I/O
•
Fieldbus Independent Configuration
•
IP 67 Protection
•
Various I/O Styles
